File Menus; New Project; Shells; Infill - FLASHFORGE 3D PRINTER CREATOR PRO 2 User Manual

Temperature

3.2.12 File Menus

1.New Project

Click [File]-[New Project] can build a blank project. If there is an unsaved modification on
previous project, then it will inform you whether the modification needs to be saved or
not. Click [Yes] will save the modification, and then click [No] will abandon it. If click
[Cancel] or close tool tip, then it will cancel the new project.

Shells

Contains the outside shell value, capping layer value
(under vase mode, top solid layer setting is invalid.)
Perimeter Shells: Maximum is 10.
Top Solid Layers: Maximum is 30, minimum is 1.
Bottom Solid Layers: Maximum is 30, minimum is 1.
Infill
Fill Density: Fill rate.
Fill Pattern: The pattern of filling shape which effects
printing duration time.
Combine Infill: You can select the layers for combining
according to the layer thickness. The combined thickness
should not exceed 0.4mm. "Every N layers" is for all the
infills while "Every N inner layers" is only for inner infills,
which generally can save print time.
Speed
Print Speed: The moving speed of the extruder. Generally,
the lower speed is, the better print you will get. For PLA
printing, 80 is recommended.
Travel Speed: Control the moving speed of the extruder
under non- printing Status during work. For PLA printing,
100 is recommended.
Note: Modify parameters settings to get better prints as
different models need different parameters.
Extruder Temperature: Recommended extruder tempera-
ture is 220°C. Note: Different temperatures have subtle
influences in prints. Please adjust the temperature
according to the condition in order to get a good print.
Platform Temperature: To set the temperature of Platform.
Others
Cooling Fan Control: Set up the time to turn on the cooling
fan. You can pre-set the height and make the cooling fan
begin to work at the point.
40
