Add Supports; Delete Supports; Clear Supports - FLASHFORGE 3D PRINTER CREATOR PRO 2 User Manual

3.Add Supports

Supports will be added once clicking the [Add] button
position where supports needed, left-click to choose the starting point of supports, hold
down the left mouse button and drag the mouse the supports preview will show up(if
support surface doesn't need support or the support column angle is too large, the
support review will be highlighted ). Loosen the left mouse button, if support column
doesn't meet with model, then support will be generated on origin and terminal point
(the highlighted preview support won't create support structure )

4.Delete Supports

Supports will be deleted once clicking the [Delete] button
supports needed deleting, current supports and its subnode support will be highlighted,
click the left mouse button to delete these highlighted support.

5.Clear Supports

Click [Clear Supports]
via clicking [Undo] or pressing the shortcut key Ctrl+Z.
3.2.11 Print
Click print icon and print setting will pop up. Click [OK] after setting all parameters, then
choose the right files format and place, and click [Save].
Flashprint - untitle.fpp
File(F) Edit(E) Print(P) View(V) Tools(T) Help(H)
View
More
Rotate
Scale
Cut
Extruder
FlashForge Creator Pro 2
, all supports will be deleted. The operation can be repealed
Load Supports
Print
I want to： Preview
FlashForge Creator Pro 2
Machine Type：
ABS
Material Right：
ABS
Material Left：
Enable
Supports：
Enable
Raft：
Resolution：
Low（Faster）
Standard
High（Slower）
More Options >>
OK
Print
Print When Slice Done
Wall
Brim
Cancel Save Configuration
38
. Move the cursor to the
. Move the cursor to the
