Introduction; Preparing For Installation - Raven SmarTrax Installation Manual

Steering ready combine claas lexion 730, 740, 750, 760, 770, and 780

Hide thumbs Also See for SmarTrax:

Table of Contents

I ntroduction

CHAPTER

C h a p t e r 2

Congratulations on your purchase of the SmarTrax system! This system is designed to provide cutting-edge,

hands-free steering of the machine via Global Positioning System (GPS) coordinates.

This manual applies to the following machines:

MAKE: CLAAS

MODEL: Lexion 700 Series (Steering Ready) - 730, 740, 750, 760, 770, and 780

CLAAS Lexion 760

FIGURE 1.

Before installing the SmarTrax system, park the machine where the ground is level, clean, and dry. Turn off the

machine and leave it turned off for the duration of the installation process.

During the installation process, follow good safety practices. Be sure to carefully read the instructions in this

manual as you complete the installation process.

P/N 016-5030-047 Rev. B
