Table Of Contents; Warnings; Introduction - Assa Abloy Yale inTouch Installation And Programming Instructions

Warnings .........................................................................................................................2
Introduction .....................................................................................................................2
Installation
Components and Tools .............................................................................................3
Door Preparation ......................................................................................................4
Prepare Lock for Installation ................................................................................. 5-6
Install Lock ............................................................................................................ 7-8
Hardware Troubleshooting ........................................................................................8
Programming
Programming Features-Menus-Keys-Definitions ............................................... 9-11
Operating Modes .............................................................................................. 12-16
Easy Mode ................................................................................................ 12-13
Advanced Mode ....................................................................................... 14-16
Miscellaneous Information ......................................................................................17
Programming Troubleshooting ...............................................................................18
Sample Pin Code Management Sheets .................................................................19
CAUTION: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
IMPORTANT: The accuracy of the door preparation is critical for the proper functioning
and security of this cylindrical product. Misalignment can cause premature wear and a
lessening of security.
Finish Care: This lockset is designed to provide the highest standard of product quality
and performance. Care should be taken to insure a long-lasting finish. When cleaning
is required use a soft, damp cloth. Using lacquer thinner, caustic soaps, abrasive cleaners
or polishes could damage the coating and result in tarnishing.
Yale® inTouch™ Stand-alone Touchscreen Access Lock combines robust cylindrical lock-
sets with a contemporary electronic aesthetic.
Users benefit from an interactive touchscreen that makes day-to-day access effortless and
offers voice-guided programming for simple updates to user information in the event of
staffing changes or security breaches.
inTouch is engineered for quick & easy installation and fits into the standard ANSI/BHMA
A156.115 cylindrical locks with lever door prep with only one additional 3/4" hole and 7
screws including latchbolt and strike.
inTouch features the choice of "Easy" or "Advanced" operating modes. Locks are shipped
as a default from the factory in "Easy" mode. The desired operating mode should be de-
termined before the completion of lock installation, but can be changed at a later time if
required.
An ASSA ABLOY Group brand

TABLE OF CONTENTS

WARNINGS

INTRODUCTION

2
P/N 80-9150-0065-010 Rev B
