Menu and Icons
~
1
Low Battery
Definitions
Advanced Mode: See "Advanced Mode" on page 14.
All Code Lockout: Advanced mode only. This feature is enabled only by the Master code. When
enabled, it restricts all user PIN code access. When the unit is in Lockout, the red locked
padlock will appear on the screen.
Easy Mode: See "Easy Mode" on page 12.
Emergency Power Supply: 9V battery connections are located under the front of the outside
escutcheon. In the case that the 4 AA alkaline batteries are completely discharged, a 9V bat-
tery can be used to supply power to the lock. While connecting the 9V battery, the lock can
be operated as normal, thus granting access so the 4 AA alkaline batteries can be replaced.
Group Lockout: Advanced mode only. This feature can be enabled by either the Master code or
the Supervisor code. If Group Lockout is enabled through the Master code, specific Supervi-
sors and their entire group of Users will be locked out. If Group Lockout is enabled through
the Supervisor code, only Users corresponding to that Supervisor are locked out.
An ASSA ABLOY Group brand
Touch the screen with palm of hand or
fingers to begin and end actions.
Click the indicated number.
Press the Star key on the touchscreen to
Enter or Accept entry.
Press the Pound key on the touchscreen to
enter Menu mode.
Press this key to return to the previous
step or menu setting.
Repeat operation using settings indicated.
The I-Button is located under the battery
cover. Remove battery cover for access .
Slide the batter cover up and off.
2 3
Passage Mode Lockout Mode
M
Enter Master PIN code (6 digits in length).
Advanced Mode only. Factory default: 123456.
S
Enter Supervisor PIN code. Can be 4-12 digits
in length. Factory default: 1234567890.
U
Enter User PIN. Can be 4-12 digits in length.
Supervisor Serial Number (00 - 19).
Advanced Mode only.
User Serial Number (01 - 49).
Advanced mode only.
Enter value 1 - 10 (times or seconds).
Enter value 1 - 255 (seconds).
Voice guide.
4 5
Return to Previous Step Lock and Unlock - Audio and Visual
10
