Easy Mode

Provides a simple, easy-to-use system for general use. In Easy mode, a total of 9 PIN codes
are available for access. Code assignments consist of one (1) Supervisor code and eight (8)
User codes.
Supervisor
User 1
User 2
User 3
User 4
User 5
User 6
User 7
User 8
Feature
Entrance Authorization
Register/Change User Code
Set Passage Mode
Set Silent Mode
Set Language Setting Mode
Programming
Set/Change Supervisor PIN
Set/Change User PIN (1 - 8)
Operation of Lock
Touch lock with palm
of hand or fingers
to activate.
An ASSA ABLOY Group brand

OPERATING MODES

ƒ Initial programming is performed by the use of the
(located under the battery cover of the inside escutcheon) and
voice guided instruction. Subsequent changes to programming
can be performed through the touchscreen by the use of the
Supervisor code.
ƒ While in Easy mode, the lock can be programmed for Passage
mode, Silent mode or alternate Language settings. Auto Re-
lock time, wrong code entry limits and shut down times are not
adjustable and will remain as factory default.
ƒ Note: After initial set-up, individual User PIN codes can not
be added to or deleted from programming. Upon entering the
Register/Change user code function, ALL existing User codes are
deleted and must be re-entered if needed.
ƒ The operating mode can be changed from Easy to Advanced
or visa versa for any lock. Changing the mode resets the lock
to factory defaults and all prior programming and PIN codes
will be lost. See page 17 for more information.
Supervisor User
x x
x
x
x
x
I-Button Touchscreen
x
x x
Palm or touch the
Enter PIN code.
to confirm the selection.
Settings
Supervisor Code
Passage Mode
Silent Mode
Re-lock Time
Wrong Code Entry Limit
Shut Down Time
Language
key
button
Factory Defaults
1234567890
Disabled
Disabled
5 Seconds
5 Times
180 Seconds
English
Turn lever to
open door.
12
