Definitions
I-Button: Easy mode only. Located under the battery cover, the "I" button is used for changing
the default Supervisor code and can be used for programming.
Low Battery: When battery power is low, the low battery icon will begin blinking. If battery
power is completely lost, the emergency power supply can be used.
Operating Modes: inTouch™ features the choice of Easy or Advanced operating modes. The
desired operating mode should be determined before the completion of lock installation, but
can be changed at a later time if required.
Passage Mode: Easy and Advanced mode. Enabling Passage mode allows continuous entry for
non-restricted traffic. Passage mode is enabled or disabled through feature programming by
either the Master or Supervisor code. When the unit is in Passage Mode, the green unlocked
padlock will appear on the screen.
Master Code: Advanced mode only. The Master code is used for programming Supervisor
codes and also for feature settings. The Master code will not operate the lock.
Re-lock Time: After successful code entry and the unit unlocks, it will automatically re-lock
after a default of five (5) seconds. Re-lock time is adjustable from one (1) to ten (10) seconds
in Advanced mode only through feature settings.
Shut Down Time: The unit will shut down for a default of one hundred and eighty (180) seconds
and not allow operation after the wrong code entry limit has been met. Shut down time is
adjustable from one (1) to two hundred and fifty-five (255) seconds in Advanced mode only
through feature settings. When the unit is in Shut Down, the red locked padlock icon
will be flashing.
Silent Mode: Easy and Advanced mode. Enabling Silent mode shuts off the code confirma-
tion tone playback for use in quiet areas. Silent mode is enabled or disabled through feature
programming by either the Master or Supervisor code.
Status LED: Located on inside escutcheon. Flashes green to indicate lock in Passage mode.
Supervisor Code: Easy and Advanced mode. The Supervisor code is used for programming
User codes and also for feature settings. The Supervisor code will operate the lock.
User Code: Easy and Advanced mode. The User code is used for operating the lock.
User Lockout: Advanced mode only. This feature can be enabled only by the Supervisor code.
When enabled, it restricts User PIN code access only for specified User numbers corre-
sponding to that Supervisor.
Wrong Code Entry Limit: After a default of five (5) unsuccessful attempts at entering a valid PIN
code the unit will shut down and not allow operation. Wrong code entry limit is adjustable
from one (1) to ten (10) times in Advanced mode only through feature settings.
