4.1 128YDS Review

By using character set A, B and C, 128yds can encode 128 ASCII characters, numbers
from 00 to 99, and some special characters. Each character are as follows:
• Character Set A: ASCII characters 00H to 5FH
· Character Set B: ASCII characters 20H to 7FH
• Character Set C: 00 ~ 99
128 yds can be encoded as belows:
· SHIFT character
"SHIFT" make the character behind the bar code symbol and converts the first character
from the character set A to character set B, or from character set B to character set A,
beginning to recover from the second character to SHIFT previously used character set.
"SHIFT" character can only be set between A and B. it does not make the current coded
character set C character enters or exits the state.
• Character set selection character (CODE A, CODE B, CODE C)
These characters can conver the back character to character set A, B or C.
* Function character (FNC1, FNC2, FNC3, FNC4)
These functions depends on the application software. In the character set C, only FNC1 is
available

4.2 Character Set

Character set A
data
Character
Hex Decimal
NULL 00 0
SOH 01 1
STX 02 2
ETX 03 3
EOT 04 4
ENQ 05 5
ACK 06 6
BEL 07 7
BS 08 8
HT 09 9
LF 0A 10
VT 0B 11
FF 0C 12
CR 0D 13

Appendix4

Character
Hex
( 28
) 29
* 2A
+ 2B
, 2C
- 2D
. 2E
/ 2F
0 30
1 31
2 32
3 33
4 34
5 35
54
128yds
data
Character
Decimal
40 P
41 Q
42 R
43 S
44 T
45 U
46 V
47 W
48 X
49 Y
50 Z
51 [
52 \
53 ]
data
Hex Decimal
50 80
51 81
52 82
53 83
54 84
55 85
56 86
57 87
58 88
59 89
5A 90
5B 91
5C 92
5D 93
