SPRT SP-RMD11A User Manual page 18

序号 自检项目英文内容
No. Contents on Self-test receipt in
English
1 Version:R-708 1.10L01
2 Model:RM
3 Interface:RS232(EIA ， TTL)(Serial
Interface model)
Interface:RS232(EIA，TTL),USB(USB
Interface model)
4 Baud Rate:9600(No this parameter for
parallel interface model)
5 Data bit/Handshaking/Parity:8 bit /
RTS/CTS / None(No this parameter
for parallel interface model)
6 Language Status:Chiese-GB2312
7 Printing Font:12*24
8 Printing Density:Medium
9 Paper Sensor Setting:Medium
10 Power Level:3
11 Printing Direction:Reverse
12 Command System:SPMP
13 Needle Type Printer Compatible:off
14 Default Codepage:No
Self-test method:
Press "LF" button and power on, release the button within 3 seconds
(within the indicator light flickers 3 times), the printer will print out the self-test
list.
Hex printing method
Hold the [LF] button and connect the power. At this time, the red indicator
自检项目中文说明
Contents
receipt in Chinese
版本号:R-708 1.10L01
机型:RM
接 口 类 型 :RS232 串 口 (EIA ，
TTL)
接口类 型 :RS232串口和 USB
口共存
波特率:9600
串口数据位/握手方式/校验方
式:
8位/标志控制/无校验
语言:简体中文(国标一二级字
库)
字符字体:12*24
打印浓度:中
测纸传感器灵敏度:中
功耗级别:3
打印方向:反向
指令集:SPRT微打指令集
针打兼容:关闭
默认代码页:无
16
on Self-test
