This setting can be used for dot matrix printer models alternatively:
1. After selecting this setting, power consumption level still can be chosen.
2. After selecting this setting, the function of selecting font size for characters and
Chinese characters will be not supported.

3.1.5 Power supply connection

RMD11A S/T/Q/P/UH Wide Input Range:DC5V～9V
RMD11A C VS/VT/VQ/VP/VUH Wide Input Range: DC9V～24V Electricity:
3A

3.2 Light and button operation

The function of each button is different according to the different working
mode. Refer the detailed to 3.1.4. The normal working mode is as below,
SET
[SET] button is in the back of the printer, electrical outlet diagonal holes.
Press and hold on [SET] button to enter into setup mode. After normal power,
this key is invalid.
LF
Press[ LF ]button to feed paper. Press again to stop paper feeding.
Power and Error status indicator LED share one green light
Light status
Stay lighting
Blink once, off 1
Blink twice, off 1
Flashing 3 times, off
1 second
Lack of paper, waiting for has
returned to normal after the paper
second
work.
Printer head is overheat, it will be
back to normal work automatically
second
after cool down.
The heating plate of printer head is
damaged, irreversible error, need to
repair.
Instruction
Normal working
