When CODE128 ( m = 73) is choose:
· Pls refer to Appendix 5 – Related information and characters set of CODE128.
· When CODE128 is used, pls encode according to the below structions:
1. Do choose characters set (one of CODE A, CODE B and CODE C) before the barcode
data.
2. Choosing characters set is finished through sending character "{" to combine with the
other character; ASCII character "{" is finished by sending character "{" twice.
Specified
Characters
Set
SHIFT
CODE A
CODE B
CODE C
FNC1
FNC2
FNC3
FNC4
"{"
[Example] :Printing"No. 123456"
In this example, printer will print "No." by CODE B, and print the other numbers by CODE
C:
Sending Data
ASCII Hex
{S 7B, 53
{A 7B, 41
{B 7B, 42
{C 7B, 43
{1 7B, 31
{2 7B, 32
{3 7B, 33
{4 7B, 34
{{ 7B, 7B
44
Decimal
123,83
123, 65
123, 66
123, 67
123, 49
123, 50
123, 51
123, 52
123, 123
