Install Software in Boot Mode

Installing new software is normally done from the application's web interface, refer to the appli-
cation documentation. But if the application's web interface cannot be reached it is possible to
put Wireless Service Gateway WSG in Boot Mode, access the modules web interface and install
new software from there.
It is not recommended to use the module's Management port when installing software.
Two software versions can be installed on the module. One software version is active and the
other inactive in normal operation.
Figure 31: Software installation in Boot Mode
1) Put the module in Boot Mode, see
2) Select Software > Install software.
3) Click the "Browse..." button and locate the software (.pkg) file to install.
4) Select where to save the software. If two versions of the software already have been installed
on the module choose which software to replace.
5) Select if the module shall be restarted after the installation or not.
6) If "Restart after installation" is selected, choose if the last used settings or the factory default
settings shall be applied on the new software.
If you choose "Do not restart", you can later, when returning to normal operation, choose and
apply settings to software that is installed but not yet started.
If current parameters cannot be used, i.e. if software of another type has been installed,
factory default parameters will always be used.
7) Click the "Install Software" button.
A31003-M2000-J109-01-7631, 30/06/2020
Wireless Service Gateway WSG, Installation Guide
Set the Module in Boot Mode
Working in Boot Mode
on page 31.
