Handset Charging Rack
OpenScape WLAN Phone WL4/WL4 Plus
Installation Guide
A31003-M2000-J107-01-7631

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OpenScape WLAN Phone WL4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Unify OpenScape WLAN Phone WL4

  • Page 1 Handset Charging Rack OpenScape WLAN Phone WL4/WL4 Plus Installation Guide A31003-M2000-J107-01-7631...
  • Page 2 As reseller please address further presales related questions to the responsible presales organization at Unify or at your distributor. For specific technical inquiries you may use the support knowledgebase, raise - if a software support contract is in place - a ticket via our partner portal or contact your distributor.
  • Page 3: Table Of Contents

    Contents Contents 1 Introduction..........................4 1.1 Safety............................4 1.2 Regulatory Compliance Statements (EU/EFTA only).............. 5 1.3 Labeling............................ 5 1.4 Regulatory Compliance Statements (USA and Canada only)..........5 1.5 Technical Solution........................6 2 Installation and Configuration....................7 2.1 Installation of the Handset Charging Rack................7 2.1.1 General..........................7 2.1.2 Wall Mounting........................
  • Page 4: Introduction

    Introduction Safety Introduction This document describes how to install and operate the Handset Handset Charging Rack Each Handset Charging Rack charges six handsets simultaneously. Figure 1: The Handset Charging Rack Supply voltage: 100-240VAC/0.7A 50/60 Hz Building fuse for fixed installation: 10 A max.
  • Page 5: Regulatory Compliance Statements (Eu/Efta Only)

    CE mark. This Declaration of Conformity and, where applicable, other existing declarations of conformity as well as further information on regulations that restrict the usage of substances or affect the declaration of substances used in products can be found in the Unify Expert WIKI at http://wiki.unify.com under the section “Declarations of...
  • Page 6: Technical Solution

    Introduction Technical Solution • Consult the dealer or an experienced radio/TV technician for help. IC Requirements for Canada CAN ICES-3 (B)/NMB-3(B) Modifications Changes or modifications to the equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Technical Solution The following functionality is provided by the Handset Charging Rack: •...
  • Page 7: Installation And Configuration

    Installation and Configuration Installation of the Handset Charging Rack Installation and Configuration Installation of the Handset Charging Rack General The unit shall be installed by authorized personnel only. • The units shall be placed in a dry environment with a temperature range from +5° C up to + 40°...
  • Page 8: Wall Mounting

    Installation and Configuration Examples of Ways to Mount the Handset Charging Racks Different ways to mount Handset Charging Racks is shown in Figure 4: Mounting and connec- tion examples on page 10. It is possible to set up different combinations of Handset Charging Racks and Battery Pack Chargers.
  • Page 9 Installation and Configuration Figure 3: IEC C14 connector and extension cord with IEC C13 connector Installation Test 1) Connect the mains power supply cord to the wall socket. 2) Put a handset in a charging slot to check if the handset’s LED lights up. Power Supply by Fixed Connection If the Handset Charging Rack shall be connected with a fixed connection, the AC connec- tion must be done by a authorized electrician.
  • Page 10 Installation and Configuration To disconnect device To disconnect device Figure 4: Mounting and connection examples Opening the Top Cover Open the top cover by first pressing on the sides of the top cover, then lifting it upwards. Figure 5: Opening the top cover Fixed Installation in Detail Fixed installation of the first Handset Charging Rack or single unit with fixed electrical installa- tion.
  • Page 11 Installation and Configuration The IEC color code is used in the power cord supplied. Wiring color codes: Load Also called Brown Black Active Line, Hot Blue White Black Neutral Return, Cold, Grounded connector Green Green Earth Ground, Safety Earth, Earth Ground, Grounding Gr/Ye conductor Installation of Additional Units in a Serial Power Configuration...
  • Page 12 Installation and Configuration Mount the cable support holder at the unused opening in the Handset Charging Rack closer to the AC power source. The cable support holder is provided in the parts bag. See Figure 6: Mounting the cable support holder on page 12.
  • Page 13 Installation and Configuration Run the power supply cord from the additional Handset Charging Rack through the cable support holder of the previous Handset Charging Rack, see Figure 7: Securing the mains power supply cable on page 13. Figure 7: Securing the mains power supply cable Connect the power supply cord from the additional Handset Charging Rack to the unused terminal block in the Handset Charging Rack closer to the AC power source.
  • Page 14 Installation and Configuration Mount the safety cover and fasten it with one screw. Secure the mains power supply cable with two screws (2), which are provided in the parts bag, see Figure 7: Securing the mains power supply cable on page 13. 10) Replace the top cover, see Figure 5: Opening the top cover on page 10.
  • Page 15: Commissioning

    Commissioning Commissioning The commissioning includes the following: • Installation test • Charging Installation Test For Installation test, see Installation Test on page 14 in the chapter before. Charging To verify that the charging works, do as follows: Place a handset in a charging slot. Start of charging may be indicated differently depending on handset model.
  • Page 16: Operation

    Operation Operation of the Handset Charging Rack Operation Operation of the Handset Charging Rack When the Handset Charging Rack is connected to external power supply, normal operation is done as follows: Handset charging 1) Connect the Handset Charging Rack to the AC power supply. 2) Place a handset in the charging slot to start charging.
  • Page 17: Index

    Index Compliance Installation Mounting Tools...
