- Page 1 Battery Pack Charger OpenScape WLAN Phone WL4/WL4 Plus Installation Guide A31003-M2000-J106-01-7631...
- Page 2 As reseller please address further presales related questions to the responsible presales organization at Unify or at your distributor. For specific technical inquiries you may use the support knowledgebase, raise - if a software support contract is in place - a ticket via our partner portal or contact your distributor.
-
Page 3: Table Of Contents
Contents Contents 1 Introduction..........................4 1.1 Safety............................4 1.2 Regulatory Compliance Statements (EU/EFTA only).............. 5 1.3 Labeling............................ 5 1.4 Regulatory Compliance Statements (USA/Canada only)............5 2 Installation..........................7 2.1 Mounting........................... 7 2.1.1 Remove the Top Cover.....................8 2.2 Electrical Installation.........................8 2.2.1 Install Single Unit......................9 2.2.2 Install Multiple Units......................9 2.3 Charging.......................... -
Page 4: Introduction
Introduction Safety Introduction This document describes how to install and operate the Battery Pack Charger. Each Battery Pack Charger charges six batteries simultaneously. Figure 1: The Battery Pack Charger Supply voltage: 100-240VAC/0.7A 50/60 Hz Building fuse for fixed installation: 10 A max. Single Unit The Battery Pack Charger can be installed as a single unit. -
Page 5: Regulatory Compliance Statements (Eu/Efta Only)
CE mark. This Declaration of Conformity and, where applicable, other existing declarations of conformity as well as further information on regulations that restrict the usage of substances or affect the declaration of substances used in products can be found in the Unify Expert WIKI at http://wiki.unify.com under the section “Declarations of... - Page 6 Introduction Modifications Changes or modifications to the equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. A31003-M2000-J106-01-7631, 25/06/2020 Battery Pack Charger, Installation Guide...
-
Page 7: Installation
Installation Mounting Installation • A fixed electrical installation must be done by an authorized electrician. • Maximum five units may be connected in a fixed electrical installation. • The unit shall be placed in a dry environment with a temperature range from +5° C to + 40° C (41°... -
Page 8: Remove The Top Cover
Installation Electrical Installation 3) Measure and mark the drill holes by using the dimensions in <Blue>Figure 4) Drill and fasten the unit to the wall with four screws. Figure 2: Mounting dimensions in mm - Charging Rack seen from back Remove the Top Cover Remove the top cover by first pressing on the sides of the top cover, then lifting it upwards. -
Page 9: Install Single Unit
Installation Install Single Unit It is not allowed to supply more than one unit by the power cord with the C14 connector. Figure 4: IEC C14 connector and extension cord with IEC C13 connector Test Installation 1) Connect the power cord to the wall outlet. 2) Place a battery in the charging slot. - Page 10 Installation To disconnect device To disconnect device Figure 5: Units mounted and connected in a fixed installation (example) Install First Unit To install the first unit: 1) Remove the C14 connector from the power cord. 2) Measure, cut and strip the power cord. 3) Connect the power cord to the disconnect device.
- Page 11 Installation Remove the safety cover from the unused terminal block. Figure 6: Remove safety cover Mount the cable support holder at the unused opening on the previous unit. The cable sup- port holder is provided in the parts bag. Figure 7: Remove safety cover Remove the C14 connector from the additional unit.
- Page 12 Installation Cut and strip the power cord to the length required. Run the power cord through the cable support holder of the previous unit. Connect the power cord of the additional unit to the unused terminal block in the previous unit.
-
Page 13: Charging
Installation Charging Test Installation 1) When the fixed installation is completed, apply AC power by switching on the disconnect de- vice. 2) Place a battery in the charging slot. 3) A yellow LED indicates that charging starts while a green LED indicates a fully charged bat- tery. -
Page 14: Troubleshooting
Troubleshooting Troubleshooting Fault Solution Charging does not start Check that the battery is properly inserted in the charger. Check the AC power supply connection. A31003-M2000-J106-01-7631, 25/06/2020 Battery Pack Charger, Installation Guide...
