Introduction

The Wireless Service Gateway WSG is the hardware platform for Linux based applications such
as messaging, alarm handling, administration and device management.
Figure 1: The Wireless Service Gateway WSG
Supply voltage:
Current con-
sumption:
Delivery includes:
A31003-M2000-J109-01-7631, 30/06/2020
Wireless Service Gateway WSG, Installation Guide
100 – 240 V AC ±20%
12 – 24 V DC -25% / +20%
Max 275 mA at 100 V AC input
Max 1 A at 12 V DC input
Wireless Service Gateway WSG hardware
The Getting started and Safety document: "Wireless Service Gateway
WSG – EMBEDDED LINUX SERVER INCLUDING SAFETY INSTRUC-
TIONS"
Two assembly brackets
Four screws size 3.5×40 together with four wall plugs
Four MFT screws size M3×6 for fastening the assembly brackets
Power cable
