Description
Flashing Patterns
Fixed light indicates normal state
Slow flashing light indicates medium attention
Quick flashing light indicates high attention
Status OK
Starting up/ shutting down
Feedback (1 second)
Error/fault
Warning
Boot mode
Demonstration mode
Waiting for automatic
startup (1 m inute)
T roubleshoot mode and
during firmware upgrade
Mass storage mode
Secured settings
Indicates that manual confirmation is required
Confirmation is done and
setting can be activated
Pow er
Power OK
Closing down caused by
low voltage
Low voltage*
* also used if the Power parameter conflicts
with the actual setup.
Figure 3: LED indications
12
Status LED
Blue
Blue
Blue
Red
Red
Yellow
Yellow
Yellow
Yellow
Status LED
Yellow
Pow er LED
Blue
Red
Red
A31003-M2000-J109-01-7631, 30/06/2020
Wireless Service Gateway WSG, Installation Guide
Mode LED
Blue
Blue
Blue
Mode LED
Blue
Blue
