LED beacon notifications
- Legend
PURPLE BLINKING
Three purple blinks indicate that the user has been identified
by the Charge Point through Presence recognition.
WHITE LIGHT
White light indicates that the Charge Point is running an
auto-diagnostic. For further information, please refer to
Section "D - Diagnostic" in Chapter 8.
RED BLINKING
Red blinking light indicates that the Charge Point is not
working properly. The number of blinks informs about
the error type. For further information about the possible
errors, please refer to Section "A - Blinking red errors" of
this chapter.
YELLOW BLINKING
Yellow light blinking indicates that the Charge Point is not
working properly. The number of blinks informs about
the error type. For further information about the possible
errors, please refer to Section "B - Blinking yellow status"
of this chapter.
