Wallbox eNext User Manual
4
Plug&Charge identification method is set by factory default and enables the user to
start a charging transaction without an identification. This configuration could be
adequate for equipment placed in private areas where identification is not required.
A
When the Charge Point LED beacon is green in a fade-in/fade-
out effect, it means that the unit is available and ready to start
a charge transaction.
B
To start the charge transaction, connect the vehicle to the Charge Point.
C
Once the charge transaction has started, the LED beacon will
turn blue in a fade-in/fade-out effect.
D
In some cases the charge transaction can be stopped due to
different causes such as:
12
Standby
Start charging
Charging
Charge stopped
