Wallbox eNext User Manual
11
The LED beacon on the Charge Point informs about
different status or error messages, using different colors
and sequences.
GREEN LIGHT
Green light indicates 'Presence recognition' identification
method is enabled and that the Charge Point is waiting for
a user identification.
GREEN FADE-IN/ FADE-OUT LIGHT
Green fade-in/fade-out light indicates that the Charge Point
is available to start a charge transaction and waiting for the
user to connect the vehicle.
BLUE LIGHT
Blue light indicates that the vehicle is connected but charge
transaction is not being performed.
BLUE FADE-IN/FADE-OUT LIGHT
Blue fade-in/fade-out light indicates that the charge
transaction is being performed.
38
