Ensuring a Level Surface
(Adjusting Desk Front Roller)
(To remove any bow in top if
necessary)
1.
Loosen front screw with a 3/16" hex driver.
2.
Slide bracket forward until
worksurface is level.
3.
Tighten screw.
Ensuring a Smooth Sliding Surface
(Side-to-side adjustment)
(To align worksurface to
understructure if necessary)
1.
Loosen rear screw with a 3/16" hex driver.
2.
Slide worksurface left to right
until centered relative to frame.
3.
Tighten screw.
ADJUSTING DESK
FRONT ROLLER
ADJUSTING DESK
BEAM
WORKSURFACE WORKSURFACE
Page 15 of 24
939500367 Rev E
