Ordering Information; Bill Of Materials - Analog Devices EVAL-AD7386FMCZ User Manual

UG-1615

ORDERING INFORMATION

BILL OF MATERIALS

Table 4. Bill of Materials
Reference Designator
U1
U2
U3
U4
U6
U7
U8
U9
A1, A2, A3, A4
A5, A6
C1, C10, C11, C12, C13, C32, C33, C38, C39,
C45, C47, C58, C59, C69, C70, C86, C87
C22, C23, C29, C30
C27, C28, C34, C35, C41, C42, C49, C50
C31, C63, C64
C37, C46, C52, C56, C60, C65, C68, C78, C84
C48, C51, C74
C55, C57, C66, C71, C72, C75, C76, C77, C80,
C81, C82, C83, C85
C79
C88, C89
D1
DS1
EXTREF, J1, J2, J3, J4
GND1, GND2, GND3, GND4
L1
LK1, LK2, LK3, LK6
LK4, LK5
Description
Single-ended input, dual, simultaneous
sampling 16-bit successive approximation
register (SAR) ADC
Very low quiescent current, 150 mA, low
dropout (LDO) regulator, 3.3 V output
voltage
Ultralow noise, high accuracy voltage
reference
800 mA, dc-to-dc inverting regulator
Very low quiescent current, 150 mA,
LDO regulator, 2.3 V output
2
2 kb serial I C bus electronically erasable
programmable read only memory
(EEPROM), 1.8 V to 5.5 V
Low noise, complementary metal-oxide
semiconductor (CMOS) LDO regulator,
5.0 V output voltage
Low noise, linear regulator
Low power, rail to rail op amps
180 MHz rail-to-rail input and output
amplifier
0.1 μF, capacitors, ceramic chip multilayer,
X7R
330 pF, ceramic capacitors, NP0, 0603
10 μF, ceramic capacitors, multilayer, X5R
2.2 μF, multilayer ceramic capacitors, X5R,
0805
1 μF, chip ceramic capacitors, X7R
0.1 μF, ceramic capacitors, X7R
10 μF, ceramic capacitors, X5R, general-
purpose
0.022 μF, ceramic capacitor, X7R, 0402
2.2 μF, ceramic capacitors, X5R, general-
purpose
Schottky diode, barrier rectifier
LED chip lamp green 525 nm (clear)
Connector PCB SMB coaxial straight jacks
Connector PCB test points, black
Inductor power, wound ferrite
Connector PCB headers, 2.54 mm pitch,
SIL, vertical printed circuit tail
Connector PCB, 6-positon, male headers,
unshrouded double row straight,
2.54 mm pitch, 5.84 mm post height,
2.54 mm solder tail
Rev. A | Page 20 of 21
EVAL-AD7386FMCZ
Manufacturer Part Number
Analog Devices AD7386
Analog Devices ADP166
Analog Devices ADR4533
Analog Devices ADP5075
Analog Devices ADP166
ST Microelectronics M24C02-R
Analog Devices ADP7104
Analog Devices ADP7182
Analog Devices ADA4896-2
Analog Devices ADA4807-1
Vishay VJ0603Y104KXAAC31X
Kemet C0603C331J5GACTU
TDK C2012X5R1E106K085AC
Taiyo Yuden LMK212BJ225KD-T
Murata GCM21BR71E105KA56L
Kemet C0805C104J5RACTU
Murata GRM21BR61C106KE15L
AVX 0402YC223KAT2A
Murata GRM155R60J225KE95D
NXP PMEG2005AEL,315
Semiconductors
Kingbright APT1608LZGCK
Electronic
Amphenol SMB1251B1-3GT30G-50
Components TP-104-01-00
Corporation
TDK VLF252015MT-6R8M
Harwin M20-9990345
Samtec Inc. TSW-103-07-F-D
User Guide
