UG-1615

EVALUATION BOARD CIRCUITRY

SOCKETS AND CONNECTORS

The connectors and sockets on the EVAL-AD7386FMCZ are
described in Table 3.
The default interface to the EVAL-AD7386FMCZ is via the 160-
way connector, which connects the EVAL-AD7386FMCZ to the
EVAL-SDP-CH1Z. If using the EVAL-AD7386FMCZ in
standalone mode, communication is achieved via the P3
header pins.
Table 3. On-Board Connectors
Connector Function
J1 Negative analog input for Channel A
J2 Positive analog input for Channel A
J3 Negative analog input for Channel B
J4 Positive analog input for Channel B
P1 Amplifier mezzanine card inputs
P2 Amplifier mezzanine card outputs
P3 Digital SPI signals
P4 Main board power supply (12 V) for all internal voltage regulators
P5 ADC power supply and digital SPI power supply
P6 Amplifier power supply
P7 Field-programmable gate array (FPGA) mezzanine card (FMC) to low pin count (LPC) connector
EXTREF External voltage reference

TEST POINTS

There are several test points and single in line (SIL) headers on
the EVAL-AD7386FMCZ. These test points provide easy access
to the signals from the evaluation board for probing, evaluation,
and debugging.
