The motion detection is pretty straight forward, the DVR simply compares one frame to another. A sufficient amount of difference is interpreted as motion. When the
motion is detected, the system can be set to automatically initiate recording. In this menu you can select the channels where you want the motion based recording to take
place.
By default, the whole screen is marked for motion detection (red blocks). If you want to disable the motion detection on an area, you need to click the grid cursor and then
drag the mouse to highlight the scope to unmark the area (transparent block).
If you set the motion detection at a high sensitivity level ("8" is the most sensitive) then the frequency of false alarm events increases. Vice versa if the sensitivity level is
too low ("1" is the least sensitive), you might increase the risk that a significant motion event will not trigger the motion detection to record.
• Show Message: Check the box to display "
when the motion is detected.
• Send email: You can let the DVR to send you an auto-email when
the motion is detected. To set up the e-mail schedule, please see
"Network: Email & Email Schedule" on page
• Full Screen: If this function is enabled and a motion is detected in
a channel, you will see that channel in full screen.
• Record Channel: Here you can select which channels you want
to include to the motion detection. If the motion is detected, the
recroding will start immediately on those channels.
Easy Link PLUS Series DVR
20

Alarm: Motion

• Channel:
• Switch
through KView Link PLUS app you can configure to receive a push notification on your smart
phone when such event takes place.
• Sensitivity: Set the sensitivity level.
• Buzzer: The DVR can use its internal buzzer to emit an alarm tone. You can set the buzzer duration
in seconds when the motion is detected.
• Post Recording: You can set how long after an event occurs that the DVR will continue to record.
The recommended recording length is 30 seconds but it can be set higher up to 5 minutes.
• Area: To setup motion area, click Setup.
" icon on the screen
M
18.
Select the channel you want to set the motion detection.
Channel: Enabling this feature allows motion detection for the specific channel and
To unmark the
area
