Record: Record & Mainstream - KGuard Security Easy Link PLUS Series User Manual

Configure the recorded video parameters here. All the modifications you apply to these settings will affect the recorded video saved into the HDD.
Easy Link PLUS Series DVR
14
Record: Record & Mainstream
• Channel: Select the channel to set its recording parameters.
• Record Switch: Enable in order to allow the video to be recorded to the HDD.
• Pre-Record: If this option is enabled, the DVR starts recording a few seconds before an event
occurs. Use this option if your primary recording type is motion based.
• Channel: Select the channel to configure recording related information.
• Resolution: This parameter defines, how large the recorded images will be. The available options
include: 720P (1280x720) or WD1 (960×480), WHD1 (960×240), WCIF (480×240).
• FPS: This parameter defines the number of frames per second the DVR will record.
• Bitrate: This parameter corresponds to the speed of data transfer that the DVR will use to record
video. Recordings that are encoded at higher bitrates, will be of better quality.
Audio: Select this option if you want to record audio along with video and have a microphone
connected to the DVR or using a camera with audio capablility (not included). Since the audio
option is only available for the channels 1 to 4, you need to connect a camera with audio
capability to these channels.
