4. Main Board Layout:
DigiMod PFC2
CH2
Remove Jumper to
switch gain to 38 dB
Remove Jumper to
enable DSP
Remove Jumper to
insert external circuit
AC EMI FILTER
AUX
CH1
VOLTAGE
CH 1-2 CNTRL
DSP
DigiMod PFC2 - PFC4 | SERVICE MANUAL
DigiMod PFC4
AC EMI FILTER
CH4
CH2
CH 1-2 CNTRL
CH 3-4 CNTRL
Power Supply Stage
Output Stage
Control Boards
Input/Output Connectors
DSP Board
AUX
CH3
VOLTAGE
CH1
DSP
7
