DigiMod PFC2 - PFC4 | SERVICE MANUAL

1. Testing Equipment:

DigiMod PFC
PSU VOLTAGE AUX CABLE
D1
To Pin 2 of
PL1 connector
To Pin 1 or 3 of
PL1 connector
D1 = 1N4004 or UF4007
U1 = LM7812
DigiMod PFC PSU AUX Voltage Cable
CB000591.R
CB000684.R DigiMod AMP AUX Voltage Cable
Lamp (min.40W/230V, best 60W/230V) for discharging the
amplifier's capacitors bank
NOT INCLUDED
USB to Mini USB Cable
4
the power supply
U1
3 1
+15 V
DC
power supply
2
0 V (GND) from
DC
the power supply
from the
To the Module
MAINS connectors
To Pin 2 of
PL1 connector
To Pin 1 or 3 of
PL1 connector
CB000589.R DigiMod Mains DC Cable
DigiMod PFC Programmer Board | SM000886
DigiMod PFC
DC CABLE
DigiMod PFC
PSU VOLTAGE AUX CABLE
D1 U1
3 1
2
D1 = 1N4004 or UF4007
U1 = LM7812
KT000291 Interface Board
+30 V from the
DC
power supply
0 V (GND) from
DC
the power supply
+15 V from the
DC
power supply
0 V (GND) from
DC
the power supply
