DigiMod PFC2 - PFC4 | SERVICE MANUAL

Checking the Output Stage Mosfets:

DigiMod PFC2
Switch the module on in
DC, with an oscilloscope check the waveforms on the points highlighted in the figure below.
KHz
KHz
134Vp 192
134Vp 192
KHz
KHz
12.5Vp 192
12.5Vp 192
16
