DigiMod PFC2 - PFC4 | SERVICE MANUAL

DigiMod PFC4

Using a M5 Socketed Wrench, remove the screw
highlighted on (Fig. 25).
Carefully remove all 8 springs indicated on (Fig. 25).
Highlighted on the figure below are all 14 screws needed
to be unscrewed in order to remove the main board from
the chassis.
(Fig. 25)
27
