Setup using the web interface
Sections
LAN Port 2, 3
and 4
LAN Port 5
WLAN
Static IP or DHCP Client
If you select DHCP client the network IP address and sub-net mask must be provided by a
DHCP server on that network. If you select Static IP address you must specify a unique IP
address and a sub-net mask.
DHCP Server Settings.
On LAN Port 1: Service you can choose to run a DHCP server. Select the check box DHCP
Server. The DHCP server settings are only displayed and can be selected when the port
mode is set to Static, otherwise the DHCP server settings are not shown.
The DHCP start and end addresses must be on the same network as the port's static IP.
VLAN port membership table
The VLAN port membership table is configured by the modem. The table is useful when
troubleshooting.
4-8
User data ports, configured automatically by the modem. The VLAN
table shows this configuration.
No connector, only internal connection.This network is connected to the
modem (iDirect GX Modem). It is set to static IP.
The wireless port can be connected to one of the other ports (service
port or one of the user data ports).
Set here which of the ports 1 to 5 you want to access with WiFi.
If LAN Port 1 is selected, you must set it to a static IP address and select
DHCP server.
Table 4-3: Setup of LAN network (Continued)
Chapter 4: Setup and operation
Preferred use
98-143492-B
