Event list
When an event is registered, the web interface shows an event icon
long as the event is active. The ACU display shows also active events. To view the event list
with active events, click the event icon from the icon bar at the top of the web interface, or
select HELPDESK > Event list from the left navigation pane.
The Event list page shows a detailed list of active events and notifications including the
time of the first occurrence, ID and severity of the event message, and a short text
describing the error. Active events are cleared from the event list when the error is cleared.
They are moved to the section Notifications and are displayed for 24 hours. All entries in
the section Notifications are cleared automatically after 24 hours and after restart of the
system. For a list of all events with description, error code (ID), explanation and remedy see
System messages on page B-1.
Self test
You can start a self test of the EXPLORER 5075GX ADU and ACU.
1. Click Self test in the HELPDESK page.
2. Click the menu item
Important
5.1.3

To point with the hand crank

If auto-acquisition is not possible you can use a hand crank to bring the antenna into the
correct position. Do as follows:
1. Press  on the keypad to go to the page MANUAL POINTING and select ENABLE.
This page sends a pointing request to the terminal.
Using the inputs from GNSS, the system calculates the azimuth and elevation look
Note
angles for the target GX satellite.
2. Press  until ENABLE/DISABLE is selected, and select ENABLE, press OK to initiate
the selection.
The antenna must be in the state MANUAL POINTING. Else, deploy and wait until this
state is shown.
3. Use the included hand-crank for axis movement in the event of a loss in power.
Access to the azimuth and elevation axis ports is located at the lower rear side of the
unit.
4. Insert the Unbraco key (5 mm) into the holes for azimuth and elevation. One turn of the
key is equal to 0.1 degree.
98-143492-B
Self test
.
Warning! The EXPLORER 5075GX will reboot to perform the self test.
Rebooting the ACU will terminate all existing connections.
