IPC910H Series User's Manual
Suspend Type
If this item is set to the default Stop Grant, the CPU will go into Idle
Mode during power saving mode.
Suspend Mode
After a selected period of system inactivity (1 minute to 1 hour), all
devices except the CPU shut off. The default value is "Disabled".
Disabled The System will never enter the SUSPEND mode.
1/2/4/6/8/10/2
It defines continuous idle time before the system
0/30/40
entering the SUSPEND mode.
Min/1 Hr
If any item defined in (J) is enabled and active, the
SUSPEND timer will be reloaded.
HDD Power Down
If HDD activity is not detected for a specified length of time in this
field, the hard disk drive will be powered down while other devices
remain active.
Soft-Off by PWR-BTTN
This option only works with systems using an ATX power supply. It
also allows users to define which type of soft power OFF sequence
the system will follow. The default value is "Instant-Off".
This option follows the conventional manner of system
performance when turning the power to OFF. Instant-
Instant-Off
Off is a software power OFF sequence requiring the
power supply button is switched to OFF.
Upon the system's turning OFF through the power
switch, this option will delay the complete system power
OFF sequence approximately 4 seconds. Within this
Delay 4 Sec.
delay period, the system will temporarily enter into the
Suspend Mode enabling you to restart the system at
once.
Power On by Ring
This option allows the system to resume or wake up upon detecting
any ring signals coming from an installed modem. The default value
is "Enabled".
Resume by Alarm
If enable this item, the system can automatically resume after a
fixed time in accordance with the system's RTC (realtime clock).
Press <Esc> to return to the Main Menu page.
48
Phoenix-Award BIOS Utility
