IPC910H Series User's Manual
COM1 RS232/422/485 Jumper Setting
Jumper
Description
COM1 RS-232
(Default)
RS-422
RS-485
Backplane Jumper Setting
Use this jumper to select PCIe x1 or PCIe x 4 by the following setting.
Jumper Description
PCI Slot 1 PCIe x 1
Function
Select
8
Jumper Setting Description
JP2 JP3
JP2 JP3
JP2 JP3
Jumper Setting Description
1 PCIe x 4
Jumper Setting
JP4
JP4
JP4
Jumper Setting
Introduction
