IPC910H Series User's Manual
3.
If the cooling solution prevents you from accessing the processor
socket, you may need to remove it. Instructions on how to
remove your cooling solution should be provided in the
documentation that came with the system.
4.
To un-install the current processor, use a screwdriver to
disengage (open) the socket actuator, as shown in Figure 1
below. (The most commonly used sockets are Molex* or
FoxConn* sockets, so they are used in the illustrations below.)
The socket actuator should open after only a half turn or so, and
you should then be able to remove the processor with your
fingers.
Procedure of Installation:
Step 1
Turn off the system.
Step 2
Disconnect the power connector.
Step 3
Loosen screws to remove the top and side covers from the
chassis.
12
Hardware Installation
