Grassi Compatibili; Pulizia; Verniciatura - BONFIGLIOLI HDP Series Installation Use And Service Manual

6.6

GRASSI COMPATIBILI

ü Klüber Staburags NBU 8 EP (per i cu-
scinetti)
ü Shell Tivela GL 00 (alternativa per in-
ü Klüberpaste 46 MR 401 (per facilitare
ü
6.7 VERIFICA DELLO STATO
DI EFFICIENZA
ü
sulla carcassa
ü
ü
ü
6.8

PULIZIA

6.9

VERNICIATURA

Nel caso il riduttore debba es-
sere verniciato, proteggere pre-
ventivamente la targa di identi-
che vengano in contatto con il solvente
curare la compatibilità e l'adesività del
prodotto.
6.6 COMPATIBLE GREASES
ü Klüber Staburags NBU 8 EP (for bear-
ings)
ü Shell Tivela GL 00 (alternative for
greased gear trains)
ü Klüberpaste 46 MR 401 (to facilitate
coupling of cylindrical parts)
ü ITP Fluorocarbon gel 880 (for moving
-
contact seals)
6.7 CHECKING OPERATIONAL
EFFICIENCY
ü Clean any dust off the gear unit cas-
-
ings.
ü Check that the noise generated at con-
stant load does not vary. Excessive vi-
- bration or noise can indicate wear of
- the gear train or failure of a bearing.
ü Check for lubricant leaks from the gas-
- kets/seals, plugs and casings.
ü Check all bolted couplings for wear,
deformation and corrosion and tighten
them down fully without over tighten-
ing.
-
-
-
6.8 CLEANING
- Clean all dust and process waste off the
- gear unit. Do not use solvents or other
products which are incompatible with the
unit's construction material and do not di-
rect high pressure jets of water at the gear
unit.
6.9 PAINTWORK
- HDP gearboxes in sizes 60 to 90 are exter-
- nally and internally painted in oven hard-
ened epoxy resin and polyester powder
paint that provides an excellent level of
- protection against corrosion and is suitable
- for outdoor installations. The colour is RAL
7042 grey.
HDP gearbox sizes 100 to 140 on the other
hand, are internally and externally spray
painted with an epoxy primer, and then
enamel. The total thickness of the paint is
80-100 μm.
If the gear unit is to be painted,
protect the data plate and seal
rings against contact with the
paint or solvent and take all necessary
care to ensure that the paint is fully
- compatible with and adheres properly
to the gear unit.
6.6 KOMPATIBLE FETTE
ü Klüber Staburags NBU 8 EP (für La-
ger)
ü
ü
ü
6.7 EFFIZIENZTEST
ü
ü
ü
ü
6.8 REINIGUNG
6.9 LACKIERUNG
Beim eventuellen
onsschild und die Öldichtringe
nicht mit Lösungsmittel in Berührung
kommen, und alle Vorsichtsmaßnahmen
ergreifen, um die Kompatibilität und Haf-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Lackieren
-
33
