LOAD TAPE ROLL CONTINUED
2. Reposition the roller for gummed in or gummed
out tapes.
Figure 10A
With machine switched on, tape loaded and water in
reservoir:
1.
For preset lengths of tape: Press the numbered key
that corresponds to the desired length.
2. Add 2" to preset lengths. For example, to make a 10"
length of tape: First, push the +2 key (light comes
on), then push the '8' key. Dispenser makes a 10"
length of tape. Push the +2 key again to turn off
this feature.
3. For custom tape lengths: Press and hold the
green "Random Length" key until the desired length
is dispensed.
PROGRAMMING TWO LENGTHS OF TAPE
You can program the dispenser to memorize one or two
different tape lengths with the Short Length and Long
Length keys.
NOTE: Programmed keys must be reset each
time the dispenser is switched on.
1. Set Short Length: While holding down the Short
Length key, press the number key that corresponds
to the shorter length desired. Release both keys to
set the short length.
2. Set Long Length (second length): while holding
down the Long Length key, press the number key
that corresponds to the longer length desired.
Release both keys to set the long length.
PAGE 4 OF 18
SETUP INSTRUCTIONS CONTINUED
Gummed
In
OPERATION
3. Insert tape roll between guide plates and over roller
so tape is positioned gummed side down. Feed the
tape under the upper paper guide and white wheel.
(See Figures 10A & 10B)
Figure 10B
3. Use the Short Length key to dispense your shorter
length and the Long Length key to dispense the
longer length.
4. Slide the color-coded sliding indicators next to the
number keys to mark your two chosen lengths.
PROGRAMMING INTERMEDIATE LENGTHS OF TAPE
Use this procedure to dispense intermediate lengths of
tape (example, 18" or 22" lengths).
1.
Press the +2 key (indicator light is on). This adds 2" to
any preset number key you choose.
2. Follow Steps 1-4 in "Programming Two Lengths of Tape."
USING THE TOP HEATER
Use the top heater in cold conditions or with particular
types of paper tape. Heats up within 3 minutes.
1.
Switch heater ON. Press the thermometer icon key
(light comes on).
2. Switch heater OFF. Press the thermometer icon key
(light goes out).
WHEN DISPENSER IS NOT IN USE
Always switch power off and unplug dispenser.
Gummed
Out
0316 IH-1036
