CAUTION! Only trained personnel should be
allowed to operate or service this machine.
WARNING! Burn Danger – Switch off power,
unplug the dispenser and allow the top heater
to cool down before performing any cleaning,
maintenance or repair.
Follow all safety and operating instructions contained in
this manual. Check state and local safety and
electrical codes.
INSTALL WATER RESERVOIR
Before using the dispenser: Wash the moistening brush
with soap and water. Rinse thoroughly.
1. Insert the brush in the water reservoir. (See Figure 1)
Figure 1
2. Switch power on.
NOTE: Make sure top heater is switched OFF
and no tape is loaded.
3. While holding down the green Random Length
button, take the reservoir in your left hand and insert
the pivot shaft into the slots on sides of dispenser.
Move shaft up to the top of the slots. (See Figure 2)
Figure 2
Reservoir
PAGE 2 OF 18

GENERAL INFORMATION

SETUP INSTRUCTIONS
Random Length
Button
Pivot Shaft
Slots
NOTE: Tape dispenser is for use with gummed
tape ONLY. Uline accepts no responsibility for
damage due to improper use.
Check Voltage – Verify that machine voltage and power
supply voltage are the same before plugging in
the dispenser.
Keep the machine clean, dry and in good operating
condition. DO NOT place or operate machine in damp
or humid environments.
4. Slide reservoir down so bottom fits over tab
on dispenser.
5. Release the green button.
INSTALL BRACKETS FOR WATER BOTTLE
1. Mount the bottle brackets on left side of machine,
inserting first the upper tooth in top slot (C) then the
lower one until it locks (D). (See Figure 3)
C
D
Figure 3
FILL WATER BOTTLE
1. Remove bottle from brackets and turn over so filler
opening faces up. (See Figure 4)
WATER Figure 4
