Hardware Specifications

Console Port (RJ-45)

The following table gives the signal designations and pin numbers for each end of the RJ-45 to
RS-232 cable that is used between the modem Console port (RJ-45) and the PC Serial port
(DB-9).
PC RS-232 Serial Port
(DB-9)
3
5
2
74
Modem
Console Signal
(RJ-45)
1 RTS
2 DTR
3 TxD
4 GND
5 GND
6 RxD
7 DSR
8 CTS
Description
Ground
Ground
Transmit Data
Ground
Ground
Receive Data
Ground
Ground
