H
ARDWARE
LED
• Power
•
Ethernet: Link, Tx, Rx, Collision
• DSL: Sync, Tx, Rx, Margin
Connectors
• DSL Interface: RJ-11
•
10Base-T: RJ-45
• Console Port: RJ-45 (serial connection to RS-232 for local configuration)

LAN Interface

•
10Base-T (IEEE 802.3i)
•
Connector: RJ-45 with MDI/MDI-X switch
MM701F User Manual
S
PECIFICATIONS
Appendix A: Specifications
71
