Comtech EF Data LGAN Installation And Operation Manual page 91

Command
Parameter (Instruction
Type Code and
Qualifier)
IP Address IPA=
Gateway IPG=
Address
Initialize ISP=
Statistics
Pointer
Serial Interface Operation
Arguments for
Command or
(Note that all arguments are ASCII
Response to
numeric codes between 48 and 57)
Query
18 bytes Command or Query.
Used to set the IP address and network prefix for the 10/100 BaseT
Ethernet management port, in the format:
xxx.xxx.xxx.xxx.yy,
Where:
xxx.xxx.xxx.xxx is the IP address, and
yy is the network prefix (8-30)
Example:
<1/IPG=192.168.001.004.24'cr'
>0001/IPG='cr''lf'
Note: Changing the IP address through the Telnet interface
requires the user to power cycle the unit, and then restart a
new Telnet session with the new IP address. The IP address
typed into the Telnet client software does not include the
range parameter, so it would be: 192.168.1.4.
Default Value: 192.168.001.004.24
15 bytes Command or Query.
Used to set the Gateway IP address for the 10/100 Base Tx
Ethernet management port, in the format:
xxx.xxx.xxx.xxx,
Where:
xxx.xxx.xxx.xxx is the IP address
Example:
<1/IPG=192.168.001.005'cr'
>0001/IPG='cr''lf'
Default Value: 192.168.001.005
None Command only.
Resets internal pointer to allow RNS? Queries to start at the
beginning of the statistics log.
Example:
<1/ISP='cr'
>0001/ISP='cr''lf'
Description of Arguments
5–17
Revision 0
Response to Query Response to
Command (Instruction
(Target to Code and (Target to
Controller) Qualifier) Controller)
IPA= IPA? IPA=
IPA? xx.xxx.xxx.xxx
IPA* .yy
IPA#
(See
description of
arguments)
IPG= IPG? IPG =
IPG? xxx.xxx.xxx.xx
IPG* x
ISP= N/A N/A
ISP?
ISP*
MN-LGAN
LGaN
Query
