Comtech EF Data LGAN Installation And Operation Manual page 90

Command
Parameter (Instruction
Type Code and
Qualifier)
High Power HPT=
Threshold
Initialize Events IEP=
Pointer
Software Image IMG=
Serial Interface Operation
Arguments for
Command or
(Note that all arguments are ASCII
Response to
numeric codes between 48 and 57)
Query
5 bytes Command or Query.
This command allows the user to set the threshold for the high
forward power alarm/fault. If the forward power rises above the
specified value, the alarm/fault will be indicated. Setting this
parameter to 00.00 effectively disables the threshold.
HPT=xx.xx,
Where:
xx.xx = a real number between 48.00 37.00 and 64.00 57.00 dBm.
(Glenn note: This was wrong for the 1kW, it was 40-60 dBm.)
Example:
<1/HPT=56.00'cr'
>0001/HPT='cr''lf'
Default Value: 00.00
None Command only.
Resets internal pointer to allow RNE? Queries to start at the
beginning of the stored events log.
Example:
<1/IEP='cr'
>0001/IEP='cr''lf'
1 byte Command or Query.
Current Active software image,
Where:
1=Bulk Image # 1 currently active
2=Bulk Image # 2 currently active
Examples:
<1/IMG=1'cr' (instructs the unit to load firmware from image #1 at
the next reset / power up).
<1/IMG?'cr' (queries the image number that the firmware loaded
during bootup)
Note: If the user sends the IMG command, and then queries the IMG
value, the numbers may not be equal because the command
tells the firmware which image to boot from at the next bootup,
and the query reports the image that the firmware booted from
on the last bootup.
Description of Arguments
5–16
Revision 0
Response to Query Response to
Command (Instruction
(Target to Code and (Target to
Controller) Qualifier) Controller)
HPT= HPT? High Power
HPT? Threshold
HPT*
IEP= N/A N/A
IEP?
IEP*
IMG= IMG? IMG=x
IMG?
IMG* (See
IMG# description for
details of
arguments)
MN-LGAN
LGaN
Query
