Thread the two M6 x 10 mm Screws through the
2.
Adjustment Module and into the Hinge Connector. Hand
tighten the M6 x 10 mm Screws by one rotation. (Figure 6)
Note: There must be a 2-3 mm gap between the Adjustment
Module and the Hinge Connector in order to complete the
following installation steps.
Figure 6
Adjustment
Module
Slide the Projector Mount Assembly onto the Projector
3.
Pole. Ensure the grooves in the Projector Pole are aligned
with the 2-3 mm gap created in Step 2. Ensure the weight of
the Projector is supported during this step. (Figure 7)
Figure 7
Projector
Assembly
Mount
Hinge Connector
14
M6 x 10 mm Screw
10 mm Wrench
Projector Pole
