Adjustment Knobs
1) Tilt
Turn clockwise to adjust the picture down.
Turn counterclockwise to adjust the picture up.
2 ) Rotate
Turn clockwise to adjust the picture counterclockwise.
Turn counterclockwise to adjust the picture clockwise.
3) Swivel
Turn clockwise to adjust the picture to the right.
Turn counterclockwise to adjust the picture to the left.
Note: An Adjustment Screw must be loosened before the
Grey Adjustment Knob can be turned. See the
Swivel Angle
1
section for more information.
2
3
3
Adjust the
