Place the four Washers over the Variable Position Screws.
2.
Thread the four Nuts onto the Variable Position Screws.
3.
Tighten using the 10 mm Wrench.
Attach the Right and Left Adjustment Module Covers by
4.
sliding the Covers together over the Adjustment Module
until the two Covers snap together. (Figure 5)
Note: To remove these Adjustment Module Covers, locate
the labels that say Open. Apply pressure to one of these
labels while pulling the two Covers apart. Repeat for the
other side.
Figure 5
Adjustment
Module Cover
Attach the Projector Mount Assembly
Place the Hinge Connector onto the Adjustment Module.
1.
Align the holes in the Hinge Connector with the holes in the
Adjustment Module.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Left
13
Right
Adjustment
Module Cover
