MCRL R5 LED Display Controller
User Manual
The MCTRL R5 is powerful and easy to use. You can quickly configure the LED
screen to light it up and display the entire input source following steps in
Screen
screen display effect.
Instruction on knob operations:




7.1 Quick Screen Configuration

Following the 3 steps below, namely Setting Input Source > Setting Input Resolution >
Quickly Configuring Screen, you can quickly light up the LED screen to display the
entire input source.

7.1.1 Step 1 Setting Input Source

Supported input sources include SDI, HDMI and DVI. Select an input source that
matches the type of the inputted external video source.
Constraints:



Figure 7-1 Input source settings
www.novastar.tech
Configuration. With other menu settings, you can further improve the LED
Press the knob to enter a menu or confirm an operation.
Rotate the knob to select a menu item or adjust a menu parameter.
Hold down the knob and BACK button simultaneously for 5s to lock or unlock all
the buttons.
Only one video input source can be selected at the same time.
SDI video sources do not support the following functions:
− Preset resolution
Custom resolution
−
The 10-bit video sources are not supported when calibration function is enabled.
7

Menu Operations

7 Menu Operations
