 6G-SDI input, resolutions up to 3840×1080@60Hz
 Maximum input resolution: 3840×1080@60Hz
 Support progressive input only
Note: Do not support input resolution settings.

HDMI1.4 input, with a maximum resolution of 3840×1080@60Hz
and minimum resolution of 800×600@24Hz

Pixel capacity: 4,140,000 pixels
 Custom resolution supported
Resolution limit with maximum width: 3840×1080@60Hz
Resolution limit with maximum height: 800×3840@60Hz
 HDCP 1.4 compliant
 Supported standard resolutions:
1024×768@(24/25/30/48/50/60/72/75/85/100/120)Hz
1280×720@(24/25/30/48/50/60/72/75/85/100/120)Hz
1280×1024@)24/25/30/48/50/60/72/75/85/100/120)Hz
1366×768@(24/25/30/48/50/60/72/75/85/100/120)Hz
1440×900@(24/25/30/48/50/60/72/75/85/100/120)Hz
1536×1536@(24/25/30/48/50/60/72/75/85/100)Hz
1600×1200@(24/25/30/48/50/60/72/75/85/100/120)Hz
1920×1080@(24/25/30/48/50/60/72/75/85/100/120)Hz
1920×1200@(24/25/30/48/50/60/72/75/85/100)Hz
2048×640@(24/25/30/48/50/60/72/75/85/100/120)Hz
2048×1152@(24/25/30/48/50/60/72/75/85/100)Hz
2304×1152@(24/25/30/48/50/60/72/75/85/100)Hz
2560×816@(24/25/30/48/50/60/72/75/85/100/120)Hz
2560×1600@(24/25/30/48/50/60)Hz
3840×1080@(24/25/30/48/50/60)Hz
 Dual link DVI input, with a maximum resolution of
3840×1080@60Hz and minimum resolution of 800×600@24Hz
 Pixel capacity: 4,140,000 pixels
 Custom resolution supported
Resolution limit with maximum width: 3840×1080@60Hz
Resolution limit with maximum height: 800×3840@60Hz
 Supported standard resolutions:
1024×768@(24/25/30/48/50/60/72/75/85/100/120)Hz
1280×720@(24/25/30/48/50/60/72/75/85/100/120)Hz
1280×1024@(24/25/30/48/50/60/72/75/85/100/120)Hz
1366×768@(24/25/30/48/50/60/72/75/85/100/120)Hz
1440×900@(24/25/30/48/50/60/72/75/85/100/120)Hz
1536×1536@(24/25/30/48/50/60/72/75/85)Hz
