Features; Video Formats Supported - NovaStar MCTRL R5 User Manual

MCRL R5 LED Display Controller
User Manual

2.1 Features











2.2 Video Formats Supported

Input Connector
HDMI1.4
Dual link DVI
6G-SDI
www.novastar.tech
1 × 6G-SDI, 1 × D-DVI and 1 × HDMI 1.4 inputs, pixel capacity of each up to
4,140,000 pixels
8 × Gigabit Ethernet and 2 × fiber optic outputs
Display rotation at any angle
Innovative architecture to enable smart configuration and shorter stage
preparation time
NovaStar G4 engine to enable a stable and smooth display with good sense of
depth and no flickering or scanning lines
Supports the new generation of NovaStar pixel level calibration technology,
which is fast and efficient.
Supports quick and easy manual adjustment of screen brightness.
Supports firmware update via USB port on the front panel.
Multiple controllers can be cascaded for uniform control.
Features
Bit Depth
8 bit
8 bit
Maximum input resolution: 3840×1080@60Hz
Note: Do not support input resolution settings or interlaced signals.
2
Sampling Format Maximum Input Resolution
RGB 4:4:4
YCbCr 4:4:4 3840×1080@60Hz
YCbCr 4:2:2
RGB 4:4:4 3840×1080@60Hz
2 Features
Features
2
