Specification - Techly IDATA EXT-E70MI User Manual

mini HDmi EXTEnDER
Q: RX indicator led lights on all the time but no image output?
A: 1) Press RX "RESET" button to reset the device.
2) Make sure RX HDMI port is well connected with TV.
3) Make sure the network cable is fine copper wire.
Q: Sender gains power from source device but no image output?
A: Try to use external DC 5V (no less than 500mA) power adapter
with USB port to provide power.

SPECiFiCATiOn

Items
HDMI signal
Support resolution
Network cable
Transmission length
Working temperature
Power supply
Power interface
Power consumption
Enclosure material
Product dimension
Weight
Color
This product is marked with this symbol. It means that
used electrical and electronic products should not be
mixed with general household waste.
There is a separate collections system for these
products in compliance with EU Directive WEEE.
EC Declaration of Conformity
With the CE sign, Techly® ensures that the product is
conformed to the basic European standards and directives
Specifications
Compatible with HDCP
480i@60Hz, 480p@6Hz, 576i@50Hz,
576p@50Hz, 720p@50/60Hz,
1080i@50/60Hz,1080p@50/60Hz
Low resistance and consumption
oxygen—free copper core (cat.6/6A/7)
CAT6: 50m at 1080p
0°C – 60°C
DC5V/1A
Micro USB
TX<2W; RX<2W
Plastic
90(W) x 45.5 (D) x 17.5 (H) mm * 2pcs
TX: 30g - RX: 30g
Black
En
11
