  • Page 1 MAGIC EEC ETI/EDI Converter Hardware/Software Manual...
  • Page 3 H a r d w a r e M a n u a l To get always information on the latest software, please register on our Homepage: http://www.avt-nbg.de Please click on Create an account under the Log In section. Now you need to enter your name/com- pany, a user name and a valid email address.
  • Page 5 Nordostpark 12 90411 Nuernberg, Germany Phone +49-911-5271-0 Telefax +49-911-5271-100 Printed in Germany, November 2013 © AVT Audio Video Technologies GmbH All Rights reserved. Reproduction in whole or in parts is prohibited without the written consent of Audio Video Technologies GmbH.

  • Page 7: Table Of Contents

    4.5.1 The MAGIC EEC main window - General 25 4.5.1.1 Interface 1 26 4.5.1.2 Reset Counter 26 4.5.2 The MAGIC EEC main window - ETI to EDI Converter 26 4.5.2.1 E1 Input 27 4.5.2.2 ETI 27 4.5.2.3 Operation 28 4.5.2.4 References 28 4.5.2.5...
  • Page 8 Submenu System Monitor 55 4.9.2 Submenu Protocol File Viewer 57 4.10 Menu Help 58 4.10.1 Submenu About MAGIC EEC 58 OPERATION VIA DISPLAY AND KEYPAD 59 Basic configuration 59 5.1.1 Setting the menu language 59 5.1.2 Configuration of the LAN 1 interface 60 MENU STRUCTURE 61 A1.1...
  • Page 9 10 MHz/2,048 MHz interface (programmable) 65 A2.4 Control and data interfaces 66 A2.4.1 LAN 1 interface 66 A2.4.2 LAN 2 interface 66 TECHNICAL DATA MAGIC EEC 69 GENERAL 71 A4.1 Order numbers 71 A4.2 Scope of delivery 71 A4.3 Declaration of conformity 71 SERVICE INFORMATION 73 A5.1...

  • Page 11: Introduction

    I n t r o d u c t i o n I N T R O D U C T I O N MAGIC EEC allows the converting of ETI to EDI and EDI to ETI signals. Typ- ical applications are Ensemble Multiplexers, which are not able to generate an ETI signal (e.g.
  • Page 12 I n t r o d u c t i o n ON AIR HOLD PRETALK Select... Call! Beendet Line Ring tone Search Name New Entry Edit Display Delete Entry Save as Quick Dial Presets Preset Load Save Delete Ring tone Signal processing Keypad 9600, no Status information...

  • Page 13: Safety

    S a f e t y S A F E T Y Introduction The unit described has been designed to the latest technical parameters and complies with all current national and international safety requirements. It operates on a high level of reliability because of long-term experience in de- velopment and constant and strict quality control in our company.

  • Page 14: Text Conventions

    S a f e t y Text Conventions In this manual the following conventions are used as text markers: Accentuation: product names or important terms LCD Text : Labelling on the front display of the system PC Text: Labelling in the PC Software The symbol marks information which facilitates the operation of the sys- tem in its daily use.

  • Page 15: Construction

    C O N S T R U C T I O N The functions of the MAGIC EEC are implemented in a single unit. The sys- tem is carried out as 19’’ x 1 U unit and has an integrated power supply.
  • Page 16 P A G E 1 6...

  • Page 17: System Description

    With the optional SDC upgrade a MAGIC EEC system can be upgraded to a full MAGIC SDC Switch & Converter. P A G E 1 7...
  • Page 18 S y s t e m d e s c r i p t i o n P A G E 1 8...

  • Page 19: Putting Magic Eec Into Operation

    When the MAGIC EEC is installed in a rack, please make sure that there is suf- ficient ventilation: it is recommended to keep a spacing of ca. 3 cm from the openings.

  • Page 20: Earthing Of The System

    P u t t i n g M A G I C E E C i n t o o p e r a t i o n Earthing of the system For EMC reasons an earthing via the earthing screw must be carried out in ei- ther case.

  • Page 21: Wiring Diagram

    P u t t i n g M A G I C E E C i n t o o p e r a t i o n Wiring diagram Alarm Signalling Optional E1 Module POWER 90- 250V AC/30W CLOCK ETI IN ETI OUT CLOCK...
  • Page 22 P u t t i n g M A G I C E E C i n t o o p e r a t i o n P A G E 2 2...

  • Page 23: Windows Pc Software

    Alternatively, you can install the software directly from the CD. You will find the installation file setup.exe in the folder Software\MAGIC EEC on the CD. Please follow the instructions of the installation routine. P A G E 2 3...

  • Page 24: Software Update From The Internet

    In addition to the PC Software, the setup also includes the Firmware for the- system. If it also has to be updated, the MAGIC EEC Software displays an er- ror message when it is started. The instructions for a Firmware update are de- scribed in CHAPTER 4.8.4, Page 53.

  • Page 25: Operation Via The Windows Pc Software

    4.5.1 The MAGIC EEC main window - General After starting the MAGIC EEC Software the main window is automatically displayed. The connection status between the PC and the system is displayed in the up- per right corner of the window:...

  • Page 26: Interface 1

    LEDs will be reset to green and all error counters are reset to 0. 4.5.2 The MAGIC EEC main window - ETI to EDI Converter To operate the MAGIC EEC as ETI to EDI Converter, please select under Con- → →...

  • Page 27: E1 Input

    W i n d o w s S o f t w a r e 4.5.2.1 E1 Input The following alarms are displayed under E1 Input if the system is operated as ETI switch. Next to the LEDs you can see the number of the occured alarms. –...

  • Page 28: Operation

    Also displayed are the DAB Mode and the Frame Length. 4.5.2.3 Operation The operation mode of MAGIC EEC is indicated under Mode. Additionally, the following status messages are displayed: – Time Reference Sync: This LED shows when the newly generated time information (time reference and TIST) is valid.

  • Page 29: The Magic Eec Main Window - Edi To Eti Converter

    W i n d o w s S o f t w a r e 4.5.3 The MAGIC EEC main window - EDI to ETI Converter To operate the MAGIC EEC as EDI Switch, please select under Configuration → → →...

  • Page 30: E1 Output

    4.5.3.4 Interface 2: E1 Output (monitoring output) NOTE This information will only be displayed if your MAGIC EEC system has the optional Monitoring Output (system version ID 800891). The following alarms are displayed under Interface 2: E1 Output (monito- ring output). Next to the LEDs you can see the number of the occured alarms.

  • Page 31: Operation

    S o f t w a r e 4.5.3.5 Operation The operation mode of MAGIC EEC is indicated under Mode. The following status messages are also displayed: – Time Reference Sync: This LED shows when the newly generated time information (time reference and TIST) is valid.

  • Page 32: Menu File

    W i n d o w s S o f t w a r e Menu File 4.6.1 Submenu Exit Via the submenu Exit you can close the MAGIC EEC software. P A G E 3 2...

  • Page 33: Menu Configuration

    The IP addresses are displayed together with the network in- terfaces. Under IP Address you need to enter the IP address of the MAGIC EEC. The standard IP address of the system is 192.168.96.102 and the standard control Port 10000.
  • Page 34 W i n d o w s S o f t w a r e Control Interface List If you want to manage several units with the PC Software, you can enter all → systems by selecting the menu item Control Interface Interface List.

  • Page 35: Submenu System

    4.7.2.1 Operation Settings 4.7.2.1.1 EEC Parameters Under EEC Parameters the operating mode for MAGIC EEC is configured. FIG. 7 EEC PARAMETERS Operation • Please select the desired operation mode for the system under Mode. You can chose between –...

  • Page 36: Edi Interface

    If you use MAGIC EEC as ETI to EDI Converter, only the configuration for the EDI output(s) will be displayed. If you operate MAGIC EEC as EDI to ETI Converter, only the configuration for the EDI input will be displayed.
  • Page 37 Output 1. Optionally you can Enable Output 2 as monitoring output. Since the MAGIC EEC provides two LAN interfaces, you can use e.g. one for data and the other one for control. The configuration of the LAN interfaces can be done under the menu item LAN Interfaces (see CHAPTER 4.7.2.3.2,...

  • Page 38: E1 Interface

    If you select this option, the alarms will be no longer displayed in the main window. • Please select which ETI Format you use. MAGIC EEC supports G.704 NA 5592, G.704 NA 5376 and G.703 NI. P A G E 3 8...

  • Page 39: Eti Parameters

    0 ... 999 msec. NOTE The NA TIST Replacement can only be selected if you operate MAGIC EEC as EDI to ETI Converter and your E1 Format is G.704 NA. • LI TIST Replacement: You can enter a value for the LI delay between 0 ...

  • Page 40: Relay/Ttl

    S o f t w a r e 4.7.2.2.1 Relay/TTL The MAGIC EEC has eight GPIO Pins (TTL) which can be programmed in- dividually. Furthermore, eight relays are also available. The following description applies to all eight configuration windowsTTL 1 (Pin 1), TTL 2 (Pin 2), TTL 3 (Pin 3), TTL 4 (Pin 4), TTL 5 (Pin 5), TTL 6 (Pin 6), TTL 7 (Pin 7) and TTL 8 (Pin 8).
  • Page 41 W i n d o w s S o f t w a r e – Input State: You can signal a certain Input State (see CHAPTER 4.5.1.1, Page 26) for the E1 Module 1 or 2. Relay ATTENTION Please note the maximum switching current is 200 mA and the maximum switching voltage is 48V per relay output.

  • Page 42: System Settings

    W i n d o w s S o f t w a r e 4.7.2.3 System Settings 4.7.2.3.1 General FIG. 14 GENERAL Display Language • Currently English and German are supported as display languages. Front Keypad • To activate the key tone for the system, please select the check box Enab- led.

  • Page 43: Lan Interfaces

    W i n d o w s S o f t w a r e 4.7.2.3.2 LAN Interfaces Under LAN Interfaces you need to enter the configuration details of the LAN interfaces. FIG. 15 LAN INTERFACE LAN 1/ LAN 2 •...

  • Page 44: Ntp

    W i n d o w s S o f t w a r e 4.7.2.3.3 Under the menu item NTP you can enable NTP and configure the NTP set- tings for your system. FIG. 16 • To activate NTP, please select Enable NTP. •...

  • Page 45: Snmp Parameter

    • Please enter the port on which MAGIC AD1 ETI receives messages under SNMP Port. The default setting is usually Port 161. • MAGIC EEC allows the addressing of up to four different Network Man- agement Systems. Please enter the corresponding IP addresses and Ports under NMS 1 (IP Adr./Port), NMS 2 (IP Adr./Port), NMS 3 (IP Adr./Port)

  • Page 46: Date And Time

    During a power breakdown the integrated system clock is buffered by an in- ternal battery . The life time of a battery is typical ca. 7 years. The replace- ment should only be done by the AVT Service. Type: 3V Lithium Battery Renata CR1220 P A G E 4 6...

  • Page 47: Login

    W i n d o w s S o f t w a r e 4.7.2.5 Login Under Login you can configure a User and an Admistrator Password. FIG. 19 LOGIN P A G E 4 7...

  • Page 48: Submenu Local Settings

    W i n d o w s S o f t w a r e 4.7.3 Submenu Local Settings Under Local Settings you can configure an automatic upload of the protocol file and decide if you want to store the settings of your configuration only for the current user or globally for all users.
  • Page 49 W i n d o w s S o f t w a r e • To store the settings globally for all users, select the option Local settings valid for every user. • Alternatively, you can select the option Store settings in custom path to define a specific folder in which your settings are stored.

  • Page 50: Menu Administration

    Via the submenu Registration you can check the activated Firmware options. FIG. 22 REGISTRATION Under Hardware the system type (MAGIC EEC/EEC) is displayed. On the tab Main all relevant features for identification like Subject Number, Factory Number, Year, Hardware Version as well as the MAC Addresses are dis- played.

  • Page 51: Submenu File System

    W i n d o w s S o f t w a r e 4.8.2 Submenu File System By selecting the submenu File System the file directory of the system (similar to the harddisk of a PC) is displayed. ATTENTION Please do not carry out any actions under File System unless our support asked you to.

  • Page 52: Submenu System Panel

    W i n d o w s S o f t w a r e 4.8.3 Submenu System Panel The System Panel is only for service purposes. Please only enter commands in the prompt, if our support ask you to do so. FIG.

  • Page 53: Submenu Firmware Download

    S o f t w a r e 4.8.4 Submenu Firmware Download The firmware required for the MAGIC EEC Switch is always included in the PC software. Via the Firmware Download the firmware can be comfortably loaded on the system.

  • Page 54: Submenu Set Factory Settings

    W i n d o w s S o f t w a r e 4.8.5 Submenu Set Factory Settings Via the submenu Factory Settings all settings are reset to the factory settings. For safety reasons a confirmation is required. FIG.

  • Page 55: Menu Extras

    W i n d o w s S o f t w a r e Menu Extras 4.9.1 Submenu System Monitor Via the menu System Monitor you receive further information about the sta- tus of the system. FIG. 28 SUBMENU SYSTEM MONITOR •...
  • Page 56 W i n d o w s S o f t w a r e – I/O Port: Currently not in use (Audio). – Ethernet MAC 1: The initialization of the ethernet module 1 has failed. – Ethernet MAC 2: The initialization of the ethernet module 2 has failed. –...

  • Page 57: Submenu Protocol File Viewer

    W i n d o w s S o f t w a r e 4.9.2 Submenu Protocol File Viewer Via the menu Protocol File Viewer you can display the Protocol File. FIG. 29 PROTOCOL FILE VIEWER In the window the alarms are listed with the following information: –...

  • Page 58: Menu Help

    Menu Help 4.10.1 Submenu About MAGIC EEC In the About MAGIC EEC dialogue, you can find the software versions of the PC software (PC Version) and of the system (Firmware Version). Further- more you can find our contact information. FIG. 30...

  • Page 59: Operation Via Display And Keypad

    O P E R A T I O N V I A D I S P L A Y A N D K E Y P A D In this chapter all basic configurations for the operation of the MAGIC EEC Switch via the front keypad and display are explained.

  • Page 60: Configuration Of The Lan 1 Interface

    O p e r a t i o n v i a D i s p l a y a n d K e y p a d 5.1.2 Configuration of the LAN 1 interface To configure the LAN 1 interface follow the instructions below: Menu –...

  • Page 61: Menu Structure

    M e n u S t r u c t u r e M E N U S T R U C T U R E On the following page you will find the complete menu structure if you select English as menu language.

  • Page 62: A1.1 Menu

    M e n u S t r u c t u r e A1.1 Menu P A G E 6 2...

  • Page 63: A2 Interfaces

    I N T E R F A C E S A2.1 MAGIC EEC The interfaces of the system are shown in Fig. 31. FIG. 31 REAR VIEW OF THE MAGIC EEC All interfaces are described below. P A G E 6 3...

  • Page 64: A2.2 Network Interfaces

    I n t e r f a c e s A2.2 Network interfaces A2.2.1 ETI interface (Module Slot 1) TAB. 1 PIN ASSIGNMENT: UNBALANCED CLOCK INTERFACE Socket: Clock (BNC) Signal Electrical characteristics Clock in Amplitude: 0.5 ... 3.5 V (Input) Impedance: 75 Ω...

  • Page 65: A2.3 Clock Interfaces

    I n t e r f a c e s A2.3 Clock interfaces A2.3.1 1 pps interface TAB. 7 PIN ASSIGNMENT: 1 PPS CLOCK INTERFACE Socket: 1pps (BNC) Signal Electrical characteristics Clock in Amplitude: 2.0 ..5.5 V (Input) 75 Ω unbalanced Ground Impedance: A2.3.2...

  • Page 66: A2.4 Control And Data Interfaces

    I n t e r f a c e s A2.4 Control and data interfaces A2.4.1 LAN 1 interface Via this interface you have the possibility to control the system and/or con- nect it to an NTP Server. Additionally you can use it as EDI input/output. TAB.
  • Page 67 I n t e r f a c e s A2.4.3 TTL/RELAY interface This interface can be used for external signalling of alarms. The programming of the available functions is possible via the Windows PC Software: – 8x TTL output, programmable –...
  • Page 68 I n t e r f a c e s P A G E 6 8...

  • Page 69: A3 Technical Data Magic Eec

    T e c h n i c a l D a t a T E C H N I C A L D A T A M A G I C E E C INE INTERFACES – E1 (ETI) 2.048-MHz, G.703/G.704 –...
  • Page 70 T e c h n i c a l D a t a EIGHT – ca. 2,4 kg DDITIONAL INFORMATION – EN 55103 Electrical safety – EN 60950 Range of temperature – +5 C to 45 ° ° Relative humidity –...

  • Page 71: A4 General

    Monitoring Output MAGIC EEC ETI/EDI Converter 800891 with Monitoring Output A4.2 Scope of delivery – MAGIC EEC ETI/EDI Converter – CD Windows PC Software – Mains power supply cable – 19’’ Mounting brackets – Manual A4.3 Declaration of conformity You will find the declaration of conformity at the end of this manual.
  • Page 72 T e c h n i c a l D a t a P A G E 7 2...

  • Page 73: Service Information

    A5.3 Repairs If, contrary to expectations, your unit is defective please fill in the attached status report and send the unit to the following address: AVT Audio Video Technologies GmbH - Repairs - Nordostpark 12 D-90411 Nürnberg Germany...
  • Page 74 S e r v i c e I n f o r m a t i o n P A G E 7 4...

  • Page 75: Index

    I N D E X Numerics Declaration of Conformity 81 Default Gateway 43 Delete Protocol File 57 1 PPS 28 Desktop device 19 10 MHz 28 Display 20 10 MHz Clock 56 Display Contrast DAC 55 19 inch rack 19 Double Frame 38 19“...
  • Page 76 I n d e x Format 27 Frame Counter 28 Frame Length 28 Frame Phase 28 Front side 15 Function Code 40 G.703-NI 38 G.704 Sync 27 G.704-NA 38 German 42 GPIO 40 green 25 Hardware requirements 23 Header CRC 27 Humidity 19 I/O Port 56 Input 27...
  • Page 77 I n d e x Menu reference number 59 Menüstruktur 61 Mode 28 monitoring output 37 Mounting brackets 19 MST CRC 28 NA TIST 27 Navigation 20 network management system 45 NMS 1 (IP Adr./Port) 45 NMS 2 (IP Adr./Port) 45 NMS 3 (IP Adr./Port) 45 NMS 4(IP Adr./Port) 45 No.
  • Page 78 I n d e x Resolution 20 RS232/Keypad 2 (PC) 42 Safety 20 Safety instructions 13 Save settings? 59 SDC Parameters 35 Select 59 Settings Location 48 Signal 27 Slot 1 Access 56 Slot 2 Access 56 SNMP 45 SNMP Port 45 Softkey 20 Software 73 Software update from the internet 24...
  • Page 79 I n d e x Version 58 Voltage changes 40 Warranty 19 yellow 25 P A G E 7 9...
  • Page 80 I n d e x P A G E 8 0...

  • Page 81: Declaration Of Conformity

    -Konformität Declaration of Conformity Name des Anbieters: AVT Audio Video Technologies GmbH Supplier’s name: Anschrift des Anbieters: Nordostpark 12 Supplier’s address D-90411 Nürnberg erklärt, dass das Produkt declares, that the product Produktname(n): MAGIC EEC Product name(s): MAGIC EEC mit den Vorschriften folgender Europäischer Richtlinien übereinstimmt:...
