AVT MAGIC AD1 ETI Hardware Manual

Dab & dab+ audio monitoring decoder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MAGIC AD1 ETI Decoder
DAB & DAB+ Audio Monitoring Decoder
Hardware/Software Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAGIC AD1 ETI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AVT MAGIC AD1 ETI

Summary of Contents for AVT MAGIC AD1 ETI

  • Page 1 MAGIC AD1 ETI Decoder DAB & DAB+ Audio Monitoring Decoder Hardware/Software Manual...
  • Page 3 H a r d w a r e / S o f t w a r e M a n u a l To get always information on the latest software, please register on our Homepage: http://www.avt-nbg.de Please click on Create an account under the Log In section. Now you need to enter your name/com- pany, a user name and a valid email address.
  • Page 5 Nordostpark 12 90411 Nuernberg, Germany Phone +49-911-5271-0 Telefax +49-911-5271-100 Printed in Germany, July 2010 © AVT Audio Video Technologies GmbH All Rights reserved. Reproduction in whole or in parts is prohibited without the written consent of Audio Video Technologies GmbH.

  • Page 7: Table Of Contents

    General saftey requirements 13 Text Conventions 14 CONSTRUCTION 15 SYSTEM DESCRIPTION 17 Functionality 17 PUTTING THE MAGIC AD1 ETI DECODER INTO OPERATION 19 Mounting 19 Connection to the mains voltage 19 Earthing of the system 20 Operational elements on the front side 20...
  • Page 8 Setting the E1 and ETI parameters 66 5.1.3 Setting the Audio interface: Analogue or digital 66 5.1.4 Activating the ETI protocol file 67 Working with the MAGIC AD1 ETI Decoder 68 5.2.1 The Status display - Operation during a connection 68 5.2.2 Working with Presets 69...
  • Page 9 MAGIC AD1 ETI MULTI SOFTWARE 71 Installing the MAGIC AD1 ETI Multi Software 71 User Interface of the MAGIC AD1 ETI Multi Software 72 Submenu Control Interface 73 MENU STRUCTURE 77 A1.1 System Settings 78 A1.2 Operation Settings 79 A1.3 Presets 80 A1.4...

  • Page 11: Introduction

    I n t r o d u c t i o n I N T R O D U C T I O N The MAGIC AD1 ETI Decoder allows the monitoring of DAB and DAB+ sig- nals with ETI (NA, G.704) and ETI (NI, G.703) format. The system monitors all audio and data channels in the ETI data stream and can decode one audio channel.
  • Page 12 I n t r o d u c t i o n Line Ring tone Search Name New Entry Edit Display Delete Entry Save as Quick Dial Presets Preset Load Save Delete Ring tone Signal processing Keypad 9600, no Status information Login Shift Automatic Answering...

  • Page 13: Safety

    S a f e t y S A F E T Y Introduction The unit described has been designed to the latest technical parameters and complies with all current national and international safety requirements. It operates on a high level of reliability because of long-term experience in de- velopment and constant and strict quality control in our company.

  • Page 14: Text Conventions

    S a f e t y Text Conventions In this manual the following conventions are used as text markers: Accentuation: product names or important terms LCD Text : Labelling on the front display of the system PC Text: Labelling in the PC Software The symbol marks information which facilitates the operation of the sys- tem in its daily use.

  • Page 15: Construction

    C O N S T R U C T I O N The functions of the MAGIC AD1 ETI Decoder are implemented in a single unit. The system is carried out as 19’’ x 1 U unit and has an integrated power supply.
  • Page 16 Construction P A G E 1 6...

  • Page 17: System Description

    FUNCTIONAL ELEMENTS OF THE MAGIC AD1 ETI DECODER Functionality With the MAGIC AD1 ETI Decoder an ETI output signal of an Ensemble Mul- tiplexer can be monitored. The system allows a simultaneous monitoring of all DAB & DAB+ Audio data streams. The system can be connected anywhere in the 2-Mbit/s signal (NA, G.704 and NI, G.
  • Page 18 The configuration and operation can be carried out via the front keypad and the illuminated display. Configuration and control is especially comfortable with the MAGIC AD1 ETI Windows PC software which is included in delivery and which communi- cates with the system via the LAN interface.

  • Page 19: Putting The Magic Ad1 Eti Decoder Into Operation

    With its dimensions (W × H × D) of 440 mm × 44,5 mm (1 U) × 260 mm the MAGIC AD1 ETI System can be used either as desktop device or mounted in 19 inch racks. Corresponding 19“ mounting brackets are included in delivery.

  • Page 20: Earthing Of The System

    P u t t i n g t h e s y s t e m i n t o o p e r a t i o n Earthing of the system For EMC reasons an earthing via the earthing screw must be carried out in ei- ther case.

  • Page 21: Wiring Diagram

    P u t t i n g t h e s y s t e m i n t o o p e r a t i o n Wiring diagram Ensemble Multiplexer TTL/RELAY HEADSET AUDIO1/AES AUDIO2/CLK AUDIO1/AES AUDIO2/CLK POWER LEFT RIGHT 90- 250V AC/30W...
  • Page 22 P u t t i n g t h e s y s t e m i n t o o p e r a t i o n P A G E 2 2...

  • Page 23: Windows Pc Software

    Please press under Software Updates the MAGIC AD1 ETI button. Subse- quently the setup programm is executed. Alternatively, you can also install the MAGIC AD1 ETI Multi Software for control of up to 20 sys- tems via LAN. P A G E 2 3...

  • Page 24: Software Update From The Internet

    In addition to the PC Software , the setup also includes the Firmware for the- system. If it also has to be updated, the MAGIC AD1 ETI Decoder Software displays an error message when it is started. The instructions for a Firmware update are described in CHAPTER 4.8.4, Page 57.

  • Page 25: Operation Via The Windows Pc Software

    In the following chapter all functions of the PC Software are described in de- tail. 4.5.1 The MAGIC AD1 ETI Decoder main window After starting the MAGIC AD1 ETI Software the main window is automati- cally displayed. FIG. 4 MAIN WINDOW...

  • Page 26: Mbit/S Status

    W i n d o w s S o f t w a r e NOTE If the connection is faulty, please check the following points: – Power supply cable is plugged in – Circuit switch of the system is in the ON position (display is available) –...

  • Page 27: Service Organization

    W i n d o w s S o f t w a r e FIG. 6 DISPLAY OF THE ETI STATUS. The LED Framing is displayed in green, if the ETI frame can be synchronised. On the right, the number of the occurred ETI framing alarms is displayed. In the next line the number of CRC Errors is shown.

  • Page 28: Subchannels

    W i n d o w s S o f t w a r e 4.5.5 Subchannels All subchannels of the data stream are displayed in the Subchannels list. FIG. 8 DISPLAY OF SUBCHANNELS The LED under Status signalises if the ISO/MPEG frame of the Audio pro- gramm can be synchronised.

  • Page 29: Alarm Counter Reset

    W i n d o w s S o f t w a r e FIG. 9 DISPLAY OF THE DECODER STATUS The following information is displayed: – Transmission mode (Mode) • Coding algorithm (DAB or DAB+) • Coding mode (Mono, Dual Channel, Stereo, Joint Stereo, SBR, PS) •...

  • Page 30: Menu File

    W i n d o w s S o f t w a r e Menu File Under the Menu File you can find all functions for the import/export of sys- tem files. 4.6.1 Submenu Operation Settings Presets Via the selection Import, the import of a Presets from a data carrier (disk, USB stick etc.) is possible.

  • Page 31: Submenu Exit

    W i n d o w s S o f t w a r e 4.6.4 Submenu Exit Via the submenu Exit you can close the MAGIC AD1 ETI Decoder software. P A G E 3 1...

  • Page 32: Menu Configuration

    W i n d o w s S o f t w a r e Menu Configuration 4.7.1 Submenu Control Interface The system is configured and operated via the LAN interface. → Select under Configuration Control Interface the option Configuration. →...
  • Page 33 If you want to control several units simultaneously, you must use the MAGIC AD1 ETI Multi Software (see CHAPTER 6, Page 71). To create a new list entry, press the New button. Please enter the settings for the LAN parameters as described above.

  • Page 34: Submenu Magic Ad1 Eti Decoder

    S o f t w a r e 4.7.2 Submenu MAGIC AD1 ETI Decoder Via the submenu MAGIC AD1 ETI Decoder the system can be configured completely. After the configuration has been changed, the following options are available: • With OK the configuration dialogue is closed and all settings are saved and applied to the system.

  • Page 35: Operation Settings

    In case you do not know which E1 (2-Mbit/s) format you use, please ask your network provider. ETI Parameter Please select which ETI Format you use. MAGIC AD1 ETI supports G.704-NA and G.703-NI. Decoded Subchannel ID after Booting If you want to select a certain subchannel to be decoded after the system has been switched on, you can enter its Subchannel ID under Decoded Subchan- nel ID after Booting.

  • Page 36: Protocol

    Protocol FIG. 14 PROTOCOL The MAGIC AD1 ETI Decoder allows an internal storage of alarm messages. To activate the Protocol function please enable the option ETI Decoder Pro- tocol. Under Size, you can configure the size of the protocol file. The available op- tions are 64 kByte, 128 kByte, 192 kByte, 256 kByte, 320 kByte and 384 kByte.

  • Page 37: Relay/Ttl

    W i n d o w s S o f t w a r e 4.7.2.1.3 Relay/TTL The MAGIC AD1 ETI Decoder has six GPIO Pins (TTL) which can be pro- grammed individually as input or output. Additionally, two relays are avail- able. FIG. 15...
  • Page 38 W i n d o w s S o f t w a r e TTL Pin as Input FIG. 16 TTL PIN AS INPUT If you use a TTL Pin as Input, you can program two different functions when the edges change: •...
  • Page 39 W i n d o w s S o f t w a r e TTL Pin as Output ATTENTION Please note that the maximum switching current is 10 mA and the maximum switching voltage is 3.3V per TTL output. FIG.
  • Page 40 W i n d o w s S o f t w a r e Relay ATTENTION Please note the maximum switching current is 200 mA and the maximum switching voltage is 48V per relay output. The following description is valid for both configuration windows Relay 1 (Pin 6+7) and Relay 2 (Pin 8+15).
  • Page 41 W i n d o w s S o f t w a r e – Decoder synced: If the Audio decoder is synchronized, the Relay Pins are closed. P A G E 4 1...

  • Page 42: System Settings

    W i n d o w s S o f t w a r e 4.7.2.2 System Settings NOTE All settings made under System Settings cannot be saved as Preset (see CHAPTER 4.7.3.3). 4.7.2.2.1 General FIG. 19 GENERAL Display Language •...
  • Page 43 Under System Name you can enter a name for the system. The name is dis- played in the headline of the PC software as well as in the MAGIC AD1 ETI Multi Software (see CHAPTER 6, Page 71) which allows a simultaneous con- trol of up to 20 systems.

  • Page 44: Audio Interface

    S o f t w a r e 4.7.2.2.2 Audio Interface MAGIC AD1 ETI supports analogue as well as digital AES/EBU Audio inter- faces. If the digital interface is used, separate Sample Rate Converters for in- put and output are available which supersedes external adjustments for dif- ferent digital sources.

  • Page 45: Lan Interface

    The Audio Level Alarm function checks the level at the Audio output of the MAGIC AD1 ETI Decoder. If the audio level falls below a certain threshold value for an indicated time interval, the alarm will be set (see CHAPTER 4.9.1, Page 59).

  • Page 46: Snmp Parameter

    – Please enter the port on which MAGIC AD1 ETI receives messages under SNMP Port. The default setting is usually Port 161. – The MAGIC AD1 ETI Decoder allows the addressing of up to three differ- ent Network Management Systems. Please enter the corresponding IP ad- dresses and Ports under NMS 1 (IP Adr./Port), NMS 2 (IP Adr./Port) and...
  • Page 47 W i n d o w s S o f t w a r e In the Alarm Traps window all system alarms that can be monitored with a network management system are listed. P A G E 4 7...

  • Page 48: Login

    The entered passwords are stored in the system. Take care in entering a pass- word. If you forget your password, the system can only be unlocked by the AVT Service. • Under USER you can assign the User Password. For saftey reasons the password needs to be confirmed under Confirm Password.
  • Page 49 W i n d o w s S o f t w a r e The user and administrator rights are allocated in the following way: Only Administrator Password configured: Password is required for changes in the configuration. Immediately available menus: →...

  • Page 50: Date And Time

    During a power breakdown the integrated system clock is buffered by an in- ternal battery . The life time of a battery is typical ca. 7 years. The replace- ment should only be done by the AVT Service. Type: 3V Lithium Battery Renata CR1220 NOTE If the FIG 0/10 is transmitted by the Ensemble Multiplexer, the time will be adjusted automatically.

  • Page 51: Submenu Presets

    W i n d o w s S o f t w a r e 4.7.3 Submenu Presets Via Presets you can save, load and edit configuration presets. 4.7.3.1 Save as ... Via the option Save as ..., the current configuration can be saved as Preset under any name (max.
  • Page 52 W i n d o w s S o f t w a r e NOTE The length of the name must not exceed 8 characters. Special characters and space characters are not allowed. Please make sure that you use clear-cut names, otherwise an error message is displayed asking you if you want to overwrite the already existing preset.

  • Page 53: Activate A Preset

    W i n d o w s S o f t w a r e FIG. 31 CONFIRMATION TO ACTIVATE A PRESET The Import button allows you to import a configuration preset from a data carrier (disk, USB stick etc.). The file extension of a preset file is always ‘.pst‘. After clicking on the Import button, the file browser is displayed via which the desired file can be selected.

  • Page 54: Menu Administration

    Via the submenu Registration you can check the activated Firmware options. FIG. 35 REGISTRATION Under Hardware the system type (here: MAGIC AD1 ETI Decoder) is dis- played. On the tab Main all relevant features for identification like Subject Number, Factory Number, Year, Hardware Version as well as the MAC Address are displayed.

  • Page 55: Submenu File System

    W i n d o w s S o f t w a r e 4.8.2 Submenu File System By selecting the submenu File System the file directory of the system (similar to the harddisk of a PC) is displayed. ATTENTION Please do not carry out any actions under File System unless our support asked you to.

  • Page 56: Submenu System Panel

    W i n d o w s S o f t w a r e 4.8.3 Submenu System Panel The System Panel is only for service purposes. Please only enter commands in the prompt, if our support ask you to do so. FIG.

  • Page 57: Submenu Firmware Download

    With the Browse button you select the firmware file. The file is always stored in the directory in which you installed the MAGIC AD1 ETI Decoder applica- tion. The standard installation directory is: C:\Programme\MAGIC AD1 ETI Decoder The name of the firmware file is „ETIDEC.ssw“.

  • Page 58: Submenu Set Factory Settings

    W i n d o w s S o f t w a r e 4.8.5 Submenu Set Factory Settings Via the submenu Factory Settings all settings are reset to the factory settings. For safety reasons a confirmation is required. FIG.

  • Page 59: Menu Extras

    W i n d o w s S o f t w a r e Menu Extras 4.9.1 Submenu System Monitor Via the menu System Monitor you receive all information about the status of the system. FIG. 41 SUBMENU SYSTEM MONITOR •...
  • Page 60 W i n d o w s S o f t w a r e – Temperature Sensor: The communication with the temperature sen- sor is faulty. – FLASH EPROM: The communication with the permanent memory is faulty. Configurations cannot be stored or read anymore. –...
  • Page 61 W i n d o w s S o f t w a r e – Local N Alarm (Local Nondeferred Alarm): The local error bit rate is higher than 10e-06. This corresponds to one bit error in four minutes. This alarm usually occurs, when the system is switched on and when the line interface is connected.

  • Page 62: Submenu Protocol File Viewer

    W i n d o w s S o f t w a r e 4.9.2 Submenu Protocol File Viewer Via the menu Protocol File Viewer you can display the ETI Protocol File. FIG. 42 PROTOCOL FILE VIEWER In the window the alarms are listed with the following information: –...

  • Page 63: Menu Help

    4.10.1 Submenu About MAGIC AD1 ETI Decoder In the About MAGIC AD1 ETI Decoder dialogue, you can find the software versions of the PC software (PC Version) and of the system (Firmware Ver- sion). Furthermore you can find our contact information.
  • Page 64 W i n d o w s S o f t w a r e P A G E 6 4...

  • Page 65: Operation Via Display And Keypad

    For the details of most functions please see the PC Software description from CHAPTER 4. Basic configuration In the following some basic configuration of MAGIC AD1 ETI Decoder are de- scribed in detail. NOTE All menus can be reached directly via a QuickMenu key sequence. For this...

  • Page 66: Setting The E1 And Eti Parameters

    5.1.3 Setting the Audio interface: Analogue or digital MAGIC AD1 ETI has analogue as well as digital Audio interfaces which you can adjust separately. The digital AES/EBU interfaces have integrated sample Rate Converters to adjust the digital Audio source to the transmission clock.

  • Page 67: Activating The Eti Protocol File

    5.1.4 Activating the ETI protocol file The MAGIC AD1 ETI Decoder allows an internal storage of alarm messages. To activate the Protocol function please follow the instructions below. Menu Operation Settings – First press the softkey...

  • Page 68: Working With The Magic Ad1 Eti Decoder

    K e y p a d Working with the MAGIC AD1 ETI Decoder In the next chapters basic functions such as selecting a component for moni- toring, displaying the service organization or the alarm messages, etc., are de- scribed in detail.

  • Page 69: Working With Presets

    – E1: no sync. 5.2.2 Working with Presets system settings The MAGIC AD1 ETI Decoder differentiates between operation settings System settings are settings that do not change during normal operation such Preset as e. g. language, date/time etc. These parameters can not be saved as since a configuration is usually only required when the system is put into ope- ration.
  • Page 70 O p e r a t i o n v i a D i s p l a y a n d K e y p a d Save Preset – : The selected is overwritten with the current Operation Set- tings.

  • Page 71: Magic Ad1 Eti Multi Software

    M A G I C A D 1 E T I M U L T I S O F T W A R E The MAGIC AD1 ETI Multi allows you to control and monitor up to twenty MAGIC AD1 ETI Decoders within a network.

  • Page 72: User Interface Of The Magic Ad1 Eti Multi Software

    M u l t i S o f t w a r e User Interface of the MAGIC AD1 ETI Multi Software The standard display of the MAGIC AD1 ETI Multi Software is shown in the figure below. FIG. 44...

  • Page 73: Submenu Control Interface

    FIG. 46 CONTROL PORT SETTINGS With the standard user interface of the MAGIC AD1 ETI Multi Software up to ten systems can be displayed in the control list. Alternatively, you can sel- ect the option Use Tree Control for system selection to display the control list as tree with parent nodes and child nodes.
  • Page 74 Example: ETI Master - Decoder 1 Add a MAGIC AD1 ETI Decoder to the control list To add a new system, click on the Add/Edit button in the Control Port Set- tings window (Fig. 46, Page 73). The window for the Communication Inter- face Parameters is displayed.
  • Page 75 Audio connection is estab- lished. Edit a MAGIC AD1 ETI Decoder of the control list To edit a system of the control list, select the desired entry and click on the Add/Edit button. The window for the Communication Interface Parame- ters is displayed.
  • Page 76 M A G I C A D 1 E T I M u l t i S o f t w a r e P A G E 7 6...

  • Page 77: Menu Structure

    M e n u S t r u c t u r e M E N U S T R U C T U R E English On the following pages you will find the menu structure if is selected as language.

  • Page 78: A1.1 System Settings

    M e n u S t r u c t u r e A1.1 System Settings Status Information Presets Save Settings Operation Settings P A G E 7 8...

  • Page 79: A1.2 Operation Settings

    M e n u S t r u c t u r e A1.2 Operation Settings Status Information Presets Save Settings P A G E 7 9...

  • Page 80: A1.3 Presets

    M e n u S t r u c t u r e A1.3 Presets Status Information P A G E 8 0...

  • Page 81: A1.4 Status Information

    M e n u S t r u c t u r e A1.4 Status Information P A G E 8 1...
  • Page 82 M e n u S t r u c t u r e P A G E 8 2...

  • Page 83: A2 Interfaces

    I N T E R F A C E S A2.1 MAGIC AD1 ETI Decoder The interfaces of the system are shown in Fig. 50. FIG. 50 REAR VIEW OF THE MAGIC AD1 ETI DECODER All interfaces are described below. P A G E 8 3...

  • Page 84: A2.2 Network Interfaces

    75 Ω unbalanced Ground Impedance: Range: 100 m A2.2.2 interface NOTE This interface is not supported in the MAGIC AD1 ETI Decoder. TAB. 4 PIN ASSIGNMENT: S 0 INTERFACE (ISDN) Socket: Western (8 pole) RJ45 Signal Electrical characteristics not used not used...
  • Page 85 I n t e r f a c e s A2.2.3 X.21 interface NOTE This interface is not supported in the MAGIC AD1 ETI Decoder. TAB. 5 PIN ASSIGNMENT: X.21 INTERFACE Connector: SUB-D 15 pole Signal Direction Electrical characteristics shield...

  • Page 86: A2.3 Control And Data Interfaces

    I n t e r f a c e s A2.3 Control and data interfaces A2.3.1 LAN interface Via this interface you have the possibility to control the system. TAB. 6 PIN ASSIGNMENT: LAN INTERFACE Socket: Western (8 pole) RJ45 Signal Electrical characteristics Data out +...

  • Page 87: A2.3.3 Data/Pad Interface

    I n t e r f a c e s A2.3.3 DATA/PAD interface The DATA/PAD interface can be used as RS232 data interface. This function is currentyl not implemented. NOTE Please note that the function - input or output - of the Pins RXD and TXD are determined by the interface type DCE or DTE.

  • Page 88: A2.4 Audio Interfaces

    I n t e r f a c e s A2.4 Audio interfaces The system incorporates analogue and digital AES/EBU Audio interfaces. For switching you can use display and keypad or the PC software. A2.4.1 Analogue Audio interface TAB. 9 PIN ASSIGNMENT: ANALOGUE INPUT (AUDIO 1/2 IN) Push Socket: 3 pole XLR...

  • Page 89: A2.5 Headset Interface

    I n t e r f a c e s TAB. 14 PIN ASSIGNMENT: CLOCK OUTPUT (CLK OUT) Connector: 3 pole XLR Signal Electrical characteristics CLOCK OUT not used A2.5 Headset interface This interface allows a monitoring of the decoded audio signal as well as the audio inputs.
  • Page 90 I n t e r f a c e s P A G E 9 0...

  • Page 91: A3 Technical Data Magic Ad1 Eti

    T e c h n i c a l D a t a T E C H N I C A L D A T A M A G I C A D 1 E T I INE INTERFACES – E1 2.048-MHz, G.703/G.704 Time slot 16 is not used Signal is bridged during power failure...
  • Page 92 T e c h n i c a l D a t a NTERFACES – PAD not yet implemented V.24/RS232 IRT Rec. compliant 38400, 57600, 115200 Baud max. 127 bytes per frame @ 115200 Baud ONTROL INTERFACES – LAN RJ45 –...
  • Page 93 T e c h n i c a l D a t a Range of temperature – +5 C to 45 ° ° Relative humidity – 5% to 85% P A G E 9 3...
  • Page 94 T e c h n i c a l D a t a P A G E 9 4...

  • Page 95: A4 General

    G E N E R A L A4.1 Order numbers MAGIC AD1 ETI Decoder 800940 A4.2 Scope of delivery – MAGIC AD1 ETI Decoder – CD Windows PC Software – Mains power supply cable – 19’’ Mounting brackets – Manual A4.3 Declaration of conformity You will find the declaration of conformity at the end of this manual.
  • Page 96 T e c h n i c a l D a t a P A G E 9 6...

  • Page 97: Service Information

    A5.3 Repairs If, contrary to expectations, your unit is defective please fill in the attached status report and send the unit to the following address: AVT Audio Video Technologies GmbH - Repairs - Nordostpark 12 D-90411 Nürnberg Germany...
  • Page 98 S e r v i c e I n f o r m a t i o n P A G E 9 8...

  • Page 99: Index

    Connect 38 Connect (level triggered) 38 A/D D/A CONVERTER 1 59 Connection Status 25 A/D D/A CONVERTER 2 59 Contact 46 About MAGIC AD1 ETI Deco- Contrast 42 der 63 Control Interface List 33 ADMINISTRATOR 48 Copyright 28 Administrator Password 49...
  • Page 100 I n d e x E1 Paramter 35 Earthing 20 Earthing screw 19 Edit 52 Email 97 EMV 20 Enabled 42 English 42 Error Level 27 Errors 28 ETI 35 ETI Mode 27 ETI Paramter 35 ETI Status 26 Exit 31 Export 30 Export (using Filter) 62 Export All 30...
  • Page 101 LEDs 29 Line frequency 19 Load 69 Location 46 Login 49 MAGIC AD1 ETI Decoder Software 65 MAGIC AD1 ETI LAN 43 MAGIC AD1 ETI LAN Software 33 MAGIC AD1 ETI Multi Software 33 MAIN EEPROM 60 Main menu 65...
  • Page 102 I n d e x Operation Settings 30 Operation settings 66 Operation Settings Presets 30 Operational elements 20 Original 28 Output 37 Password 48 PC OFFLINE 25 PC ONLINE 25 PC ONLINE ALARM 25 PC Version 63 Positive edge 38 Power consumption 19 Preset 34 Presets 30...
  • Page 103 I n d e x Signal 26 Size 28 S-Label 29 SNMP Port 46 Softkey 20 Software 97 Software update from the internet 24 Software Updates 97 Software versions 63 Space characters 52 Special characters 51 Stand-by mode 19 Start 57 Status 28 Storage 13 Subchannel Identifier 29...
  • Page 104 I n d e x P A G E 1 0 4...

  • Page 105: Declaration Of Conformity

    -Konformität Declaration of Conformity Name des Anbieters: AVT Audio Video Technologies GmbH Supplier’s name: Anschrift des Anbieters: Nordostpark 12 Supplier’s address D-90411 Nürnberg erklärt, dass das Produkt declares, that the product Produktname(n): MAGIC AD1 ETI Decoder Product name(s): MAGIC AD1 ETI Decoder mit den Vorschriften folgender Europäischer Richtlinien übereinstimmt:...
