- Page 1 User Manual CVT-SDI-MAV SDI to Universal converter Version: V2017.001...
- Page 2 Contents 1. Introduction ......................3 2. Features ........................3 3. Specification ......................3 4. Packing ........................4 5. Panles ........................4 6. Operations ........................4 6.1 Connection Diagram......................5 6.2 Front button........................5 7. Common issues and troubleshooting ..............5 7.1 Common issues ......................5 7.2 Attention ........................5 8.
- Page 3 1. Introduction CVT-SDI-MAV is a unique and powerful universal media converter, it can convert the SDI to CVBS/DVI/VGA/Ypbpr/HDMI. It also support 3.5mm audio embedded and de-embedded. With front buttons, users can adjust the color, brightness, sharpness, contrast ratio of the output images.
- Page 4 4,1360*768,1366*768,1440*900,1400*1050,1600 *1200,1680*1050,1920*1080,1920*1200 Power Power adapter AC: 110V-240V 50/60Hz DC: 12V 1500mA Consumption ≤7W Temperature Working 0℃-50℃ Storage -10℃-75℃ Humidity Storage 10%-95%RH Dimension Size 152*96*27mm Weight 200g 4. Packing SDI to MAV Converter Unit DC 12V Power adapter 5. Panels Rear Panel A: HDMI/DVI/CVBS/VGA/YPbPr source output interface(DVI-I) B: 3.5mmAudio input port C: 3.5mmaudio output port...
- Page 5 6.1 Connection Diagram 6.2 Operation of the function keys Press Menu(M) button, it will show below interface on the display: Note: Users can adjust the needed contents with the direction and Enter buttons (1) Input Source: It’s automatically detected (2) Out Resolution: Default resolution is HD(1080P60) (3) Out Port Mode: Default output connection model is YC 422(16EMB) (4) Aspect Ratio: Two models to select: 16:9 and 4:3 (5) Over Scanning: Supports images zooming from﹣10% to 10%...
- Page 6 Company or its authorized agent, the company will not have to bear additional obligations. Except using the product properly in the proper application or normal usage 9. Version Information Description of version（Document number：CVT-SDI-MAV） Date Version number Description Feb 2017 V1.01.01...
